Bright solar panel is a high efficiency monocrystalline solar panel.
The panel adopts the international standard quality management system ISO9001: 2008 to control the quality.
The solar panel has passed the international certificate IEC 61215, IEC 61730, complying with CE standard
90%power output assurance for 10 years, and 80% power output assurance for 25 years. 5 years products warranty.
|
MECHANICAL CHARACTERISTCS ABSOLUTE MAXIMUM RATING |
|
Solar Cells |
Poly crystal Si 156 mm × 156 mm
Square, 6 × 12 pieces in series |
|
Dimension |
Length: 1956mm |
|
Width: 992mm |
|
Height: 50mm |
|
Weight |
27 kg |
|
Front Glass |
3.2 mm |
|
Frame |
Anodized aluminium alloy |
|
Cable |
0.9mwire (ø 4 mm² ) |
|
Diodes |
6 pieces schottky by-pass diodes |
|
Junction Box |
IP 65 Rated |
|
|
Parameter |
Values |
Unit |
|
Operating temperature |
From -40 to +85 |
º C |
|
Typical Application |
24 V DC |
|
Hail Diameter @ 80km/h |
Up to 25 |
mm |
|
Surface Maximum Load Capacity |
Up to 5400 |
Pa |
|
Maximum Series Fuse Rating |
10 |
A |
|
IEC Application Class (IEC 61215) |
A |
|
Fire Rating (UL 1703) |
C |
|
Maximum System Voltage |
1000 V DC (IEC 61215) |
|
600 V (UL 1703) |
|
|
ELECTRICAL TYPICAL VALUES |
|
Model |
Rated Power
(Pmax) |
Tolerance |
Rated current (Imp) |
Rated Voltage
(Vmp) |
Short Circuit Current (Isc) |
Open circuit voltage (Voc) |
Module
Efficiency(%) |
|
BLD-72-6P230 |
230W |
± 3% |
6.72A |
34.1 V |
7.42 A |
43.2 V |
11.85 |
|
BLD-72-6P235 |
235W |
± 3% |
6.85A |
34.2 V |
7.54 A |
43.4 V |
12.11 |
|
BLD-72-6P240 |
240W |
± 3% |
6.98A |
34.4 V |
7.65 A |
43.6 V |
12.37 |
|
BLD-72-6P245 |
245W |
± 3% |
7.11A |
34.5 V |
7.78 A |
43.7 V |
12.63 |
|
BLD-72-6P250 |
250W |
± 3% |
7.24A |
34.6 V |
7.89 A |
43.8 V |
12.88 |
|
BLD-72-6P255 |
255W |
± 3% |
7.36A |
34.7 V |
8.01 A |
43.9 V |
13.14 |
|
BLD-72-6P260 |
260W |
± 3% |
7.47A |
34.8 V |
8.09 A |
44 V |
13.40 |
|
BLD-72-6P265 |
265W |
± 3% |
7.59A |
37.9 V |
8.15 A |
44.2 V |
13.66 |
|
BLD-72-6P270 |
270W |
± 3% |
7.71A |
35 V |
8.2 A |
44.5 V |
13.91 |
|
BLD-72-6P275 |
275W |
± 3% |
7.84A |
35.1 V |
8.28 A |
44.6 V |
14.17 |
|
BLD-72-6P280 |
280W |
± 3% |
7.95A |
35.2 V |
8.33 A |
44.8 V |
14.43 |
|
BLD-72-6P285 |
285W |
± 3% |
8.07A |
35.3V |
8.41A |
45V |
14.69 |
|
BLD-72-6P290 |
290W |
± 3% |
8.20 A |
35.4V |
8.50A |
45.2V |
14.94 |
|
BLD-72-6P295 |
295W |
± 3% |
8.31A |
35.5V |
8.57A |
45.4V |
15.20 |
|
BLD-72-6P300 |
300W |
± 3% |
8.44A |
35.6V |
8.65A |
45.6V |
15.46 |
|
BLD-72-6P305 |
305W |
± 3% |
8.57A |
35.7V |
8.73A |
45.8V |
15.72 |
|
NOCT ( Nominal Operation Temperature): 45º C± 2º C |
Voltage Temperature Coefficient: -0.35% / K |
|
Current Temperature Coefficient: -0.05% / K |
|
Power Temperature Coefficient: -0.48% / K |
|
