Bright solar panel is a high efficiency monocrystalline solar panel.
The panel adopts the international standard quality management system ISO9001: 2008 to control the quality.
The solar panel has passed the international certificate IEC 61215, IEC 61730, complying with CE standard
90%power output assurance for 10 years, and 80% power output assurance for 25 years. 5 years products warranty.
|
MECHANICAL CHARACTERISTCS ABSOLUTE MAXIMUM RATING |
|
Solar Cells |
Poly crystal Si 156 mm × 156 mm |
Parameter |
Values |
Unit |
|
Square, 6 × 10 pieces in series |
Operating temperature |
From -40 to +85 |
º C |
|
Dimension |
Length: 1640mm |
Typical Application |
24 V DC |
|
Width: 992mm |
Hail Diameter @ 80km/h |
Up to 25 |
mm |
|
Height: 50mm |
Surface Maximum Load Capacity |
Up to 5400 |
Pa |
|
Weight |
23.5 kg |
Maximum Series Fuse Rating |
10 |
|
Front Glass |
3.2 mm |
IEC Application Class (IEC 61215) |
A |
|
Frame |
Anodized aluminium alloy |
Fire Rating (UL 1703) |
C |
|
Cable |
0.9mwire (ø 4 mm² ) |
Maximum System Voltage |
1000 V DC (IEC 61215) |
|
Diodes |
6 pieces schottky by-pass diodes |
600 V (UL 1703) |
|
Junction Box |
IP 65 Rated |
|
|
ELECTRICAL TYPICAL VALUES |
|
Model |
Rated Power |
Tolerance |
Rated current (Imp) |
Rated Voltage |
Short Circuit Current (Isc) |
Open circuit voltage (Voc) |
Module |
|
(Pmax) |
(Vmp) |
Efficiency(%) |
|
BLD-60-6P190 |
190W |
± 3% |
6.71A |
27.9V |
7.38A |
36V |
11.68 |
|
BLD-60-6P195 |
195W |
± 3% |
6.84A |
28.0V |
7.51A |
36.2V |
11.99 |
|
BLD-60-6P200 |
200W |
± 3% |
6.98A |
28.2V |
7.65A |
36.4V |
12.29 |
|
BLD-60-6P205 |
205W |
± 3% |
7.15A |
28.4V |
7.78A |
36.6V |
12.6 |
|
BLD-60-6P210 |
210W |
± 3% |
7.24A |
28.6V |
7.93A |
36.8V |
12.91 |
|
BLD-60-6P215 |
215W |
± 3% |
7.38A |
28.8V |
8.06A |
36.9V |
13.21 |
|
BLD-60-6P220 |
220W |
± 3% |
7.5A |
29.0V |
8.19A |
37V |
13.52 |
|
BLD-60-6P225 |
225W |
± 3% |
7.69A |
29.2V |
8.32A |
37V |
13.83 |
|
BLD-60-6P230 |
230W |
± 3% |
7.84A |
29.4V |
8.34A |
37.1V |
14.14 |
|
BLD-60-6P235 |
235W |
± 3% |
7.94A |
29.6V |
8.40A |
37.3V |
14.44 |
|
BLD-60-6P240 |
240W |
± 3% |
8.06A |
29.8V |
8.50A |
37.5V |
14.75 |
|
BLD-60-6P245 |
245W |
± 3% |
8.18A |
30.0V |
8.60A |
37.7V |
15.06 |
|
BLD-60-6P250 |
250W |
± 3% |
8.30A |
30.2V |
8.70A |
37.8V |
15.37 |
|
BLD-60-6P255 |
255W |
± 3% |
8.42A |
30.4V |
8.80A |
37.9V |
15.67 |
|
BLD-60-6P260 |
260W |
± 3% |
8.54A |
30.6V |
8.90A |
38.0V |
15.98 |
|
NOCT ( Nominal Operation Temperature): 45º C± 2º C |
Voltage Temperature Coefficient: -0.35% / K |
|
Current Temperature Coefficient: -0.05% / K |
|
Power Temperature Coefficient: -0.48% / K |
