| Prod Model: |
YGDL |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Axis Type: |
Horizontal |
Product Description
Specifications
1. Low speed, more poles
2. Permanent magnet, high efficiency
3. Compact sturcture, low noise
4. High quality, Customizable
Other specification:
Insulation: H
Protection: IP44
Cooling: Natural cooling, wind cooling or water cooling.
Introduction:
(1)Low speed permanent magnet generators, leaving out reduction box, generating high voltage at low speed.
(2)High efficient PM generators, optimal design, compact structure, no carbon brush, no spark, do not need excitation. Protection Class: IP44. Prevent water, mud or dust getting into the generator, long life.
(3)No excitation control box, sample structure, high reliability.
(4)Smaller size, light weight, high energy density, suitable for special situations.
(5)Running effectively in the whole speed range, high generating efficiency.
(6)Using embedded type rare-earth magnet steel, suitable for bumping, reduplicate startup, and reversible operation.
(7)Adopting imported oil-contained bearings, maintenance free, high reliability, long life.
(8)The voltage, speed, power of the generator can be customized. The shape can also be changed, using spine shaft, dual shaft, front edge or other output ways.
| Power | AC Voltage | Speed | Frequency | Rated Torque | Current | Efficiency | Frame size | Weight | FOB price |
| 120 kw | 400V | 250rpm | 50Hz | 4584Nm | 186.1A | 93.1% | YGDL-355 | 1440kg |
|
| 150 kw | 400V | 250rpm | 50Hz | 5730Nm | 232.3A | 93.2% | YGDL-355 | 1480kg |
|
| 180 kw | 400V | 250rpm | 50Hz | 6876 Nm | 279.4A | 93.0% | YGDL-355 | 1560kg |
|
| 200 kw | 400V | 250rpm | 50Hz | 7640Nm | 310.1A | 93.1% | YGDL-355 | 1580kg |
|
| 250 kw | 400V | 250rpm | 50Hz | 9550Nm | 388A | 93.0% | YGDL-355 | 1560kg |
|
