Small Capacity Electric Steam Generator
1)Steam Capacity: 4-85Kg/h
2)Input Power: 3-24kW
3)Working Pressure: 7-10bar
4)Power Voltage: 110-600V
I. Product Introduction:
"FUTURE" Small capacity electric steam generator is run by power energy, no noise, no pollution. Using high quality heating elements, with a lower surface heat load and higher thermal efficiency. This product adopts cabinet design style, elegant appearance, compact internal structure and it's ideal for saving space.
1. Small Input Power(3-24KW) with higher output(4-35Kg/h).
2. Use of Nichrome Heating Element, it ensures long-term effective operation of the boiler.
3. Mini Electric Steam Generator has a compact structure with fast heating speed, reaching to use pressure by several minutes.
4. Unique built-in steam-water separator solved a problem of steam with water which brought by similar products.
IDEAL FOR CLOTHES PRESSING, LAUNDRY, HOSPITAL, FOOD PROCESSING AND GREEN HOUSE APPLICATIONS, etc...
II. Technical Parameters:
| Model | LDR0.004-0.7 | LDR0.009-0.7 | LDR0.013-0.7 | LDR0.017-0.7 | LDR0.025-0.7 | LDR0.035-0.7 |
| Item | Unit |
| Rated Steam Capacity | Kg/h | 4 | 9 | 13 | 17 | 25 | 35 |
| Rated Working Pressure | Bar / Psig | 7 / 101 (Made to order) |
| Saturated Steam Temperature | °C | 171 |
| Input Power | KW | 3 | 6 | 9 | 12 | 18 | 24 |
| Input Current | A | 6 | 9 | 14 | 18 | 27 | 41 |
| Power Source | V/Hz | 220/380,50 (Made to order) |
| Water Inlet | DN | 15 | 15 | 15 | 15 | 15 | 15 |
| Steam Outlet | DN | 15 | 15 | 15 | 15 | 15 | 15 |
| Blowdown Valve | DN | 15 | 15 | 15 | 15 | 15 | 15 |
| Safety Valve | DN | 15 | 15 | 15 | 15 | 15 | 15 |
| Dimension | mm | 680×520×850 | 750×550×920 | 850×600×1000 |
| Weight | kg | 50 | 75 | 79 | 85 | 92 | 118 |
