Deep Sea Genset Controller DSE5220
The DSE5220 is an automatic mains failure control module designed to provide advanced load share functionality for diesel and gas generating sets that include non-electronic/electronic engines. The module also provides excellent engine monitoring and protection features. The module monitors the mains (utility) supply and upon detection of a loss in power automatically starts the generating set.
The module has the ability to monitor under/over generator volts, over current, under/over generator frequency, under speed, over speed, charge failure, emergency stop, low oil pressure, high engine temperature, fail to start, low/high DC battery volts, fail to stop, generator short circuit protection, reverse power, generator phase rotation error, earth fault protection, loss of speed signal, fail to open, fail to close, out of sync, MPU open circuit failure, negative phase sequence and loss of excitation.
FEATURES:
Electronic engine capability
RS232 or RS485 remote communications
Modbus RTU
Pin number protected front panel programming
Engine exercise timer
Back-lit LCD 4-line text display
Multiple language options
Voltage measurement
Configurable inputs (9)
Configurable outputs (5)
Automatic start
Manual start
Audible alarm
LED indicators
Built-in governor and AVR control for easy operation and panel engineering
Engine history event log
Engine protection
Fault condition notification to a designated PC
Front panel mounting
PC configuration
Mains (utility) failure detection
Configurable alarm timers
Configurable start & stop timers
Automatic load transfer
SMS alert messaging
Multi set communications
Front panel mounting
Remote control and monitoring
