Introducing WFD400W-A wind generator with beautiful shape, safe, portable and reliable.
It is especially designed to meet the demand from individual householders for a
Renewable energy source.
The WFD400W is used to charge 24V or 36V batteries. Equipped with suitable DC to AC
Inverter, it is capable of supplying power for:
Refrigeration
Electric fan
Lights
Navigational equipment
Communication equipment
Features:
Reliable passive self furling
Autobrake slows down the blades spin when the batteries are charged
Marine quality powder coated aluminum body, all stainless steel hardware, water tight housing
Iron Boron Neodymium magnet alternator.
Reliability: The design of the body efficiently flows excess heat into the wind reducing operating
Temperature
One year warranty; Operational life expected to be in excess of 15 years.
|
Rated Power |
20 KW |
|
Max Power |
25 KW |
|
Voltage Options |
240V, 360V & Grid Tie |
|
StartWind Speed |
4 m/s |
|
Rated Wind Speed |
12 m/s |
|
MAX WIND SPEED |
45 m/s |
|
Cut-Out Wind Speed |
13 m/second |
|
Blade Pitch Control |
None, Fixed Pitch |
|
Over speed Protection |
Side furling with gravity return
& Manual braking |
|
Temperature Range |
-40 to +60 Deg. C |
|
RotorDiameter |
10 m |
|
Rotor speed |
180 rpm |
|
Bladenumber |
3 |
|
Blade material |
Reinforced fibreglass |
|
Generator |
3 phase permanentmagnet alternator |
|
Turbine Weight(kg) |
750 |
Suzhou Yueniao Machinery & Electronics Imp & Exp Co., Ltd. is one of the pioneer renewable energy business and has been in this field since 2002. We are dedicated exclusively to the business of small wind generator, mini hydroelectric generator and solar energy.
As a manufacturer with advanced technology, we are making in our own workshop the wind turbine from 300W to 20kw with CE certificates. Beside that we are dealing with business of mini hydroelectric generator from 200W up to 60KW and solar panel from 20W to 280W.
We do not claim any of its products to be the best, but we are proud to hear the owners of our products praise them. And that is what makes all the time and effort we spend on our products worthwhile.
Thank you for your support!
