| Prod Model: |
FD |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Power: |
50W/100W |
| Starting Wind Speed: |
3m/S |
| Rated Wind Speed: |
12m/S |
| Rotor Diameter: |
830mm/1050m |
| N. W.: |
2.6/2.8kg |
| Blade Material: |
Extra-Strong Engineering Plastics |
| Protection: |
Electromagnetic Torque Control and Bra |
| Rated Speed: |
1050r/M or 860r/M |
| Packing Material: |
Carton Box and Foam Material |
| Warranty: |
3years |
| Rotating Shaft: |
Horizontal |
| Number Of Blade: |
Three Blade |
| Stress Way Of Blade: |
Lift Force |
Product Description
Wind power low rpm vertical Alternator/low speed ac permanent magnet generator 600W 1KW
Our competitive advantage:
1. Have 2.6-2.8kg weight, portable use.
2. Low start-up wind speed.
3. Warranty: 3years. Free to maintance.
Feature:
1. Low start-up wind speed 2m/s.
2. Light generator, 2.6/2.8 kg.
3. CEcertificate,
4. Wind generator warranty 3years.
5. Matched controller with functions of electronic and manual brake, PWM charging, etc.
ModelFD-50
Rated power50W
Generator detail
Starting wind speed3m/s
Cut-in wind speed3.5m/s
Rated wind speed12m/s
Security wind speed45m/s
Rated DC voltage12V/24V
Rated speed1050 r/m
Rotor diameter830mm
ProtectionElectromagnetic torque control and electricity brake
Type3phases permanent magnetism synchronization generator
Material
Blade materialExtra-strong and tenacious engineering plastics
Packing materialCarton box and foam material
Package
Packing dimension615*260*210 mm
N. W&G. W(kg)2.6/3.2kg
|
Model |
FD-50 |
FD-100 |
|
Rated power |
50W |
100W |
|
Generator detail |
|
|
Starting wind speed |
3m/s |
3m/s |
|
Cut-in wind speed |
3.5m/s |
3.5m/s |
|
Rated wind speed |
12m/s |
12m/s |
|
Security wind speed |
45m/s |
45m/s |
|
Rated DC voltage |
12V/24V |
12V/24V |
|
Rated speed |
1050 r/m |
860r/m |
|
Rotor diameter |
830mm |
1050mm |
|
Rated output AC voltage |
220V/50Hz(110v/60Hz) |
|
Protection |
Electromagnetic torque control and electricity brake |
|
Type |
3phases permanent magnetism synchronization generator |
|
Material |
|
Blade material |
Extra-strong and tenacious engineering plastics |
|
Packing material |
Carton box and foam material |
|
Package |
|
Packing dimension |
615*260*210 mm |
615*260*210 mm |
|
N. W& G. W(kg) |
2.6/3.2kg |
2.8/3.5 kg |
