Name:
12kw/12kVA Silent Diesel Generator (Sh20d)
Generator Set:
Yes
Engine:
Honda/Kohler/YAMAHA/Vangard/Cummins/China Engine
Fuel:
Gasoline/Diesel
Output Power:
0-30 Kw
Frequency:
50/60 Hz
Cooling System:
Forced Air Cooling
Current:
AC/DC
Certificate:
CE, ISO 9001:2008, Saso, Tlc
Lead Time:
30 Days
Type:
Basic Diesel Generator
Installation Method:
Fixed
Stroke:
Four Stroke
Cooling Method:
Air Cooled
Output Type:
AC Single Phase
Product Description
PRODUCT DETAILS
Engine: Changchai CZ380Q Engine type: Water cooled, 4-stroke, three cylinders Starting system: Electric start Displacment: 1357CC Frequency: 50Hz Rated voltage: 220V Rated power: 12.0kw Max. Power: 13.7kw Fuel tank capaity: 30L Phase: Single Poles: 2 Drivetrain: Direct-coupled Sound level [dB(A)/7m]: 78 100% copper coil AVR
Model
SH13D
SH15D
SH20D
SH23D
SH25D
SH30D
Dimensions(mm)
1350× 750× 800
N. W(kg)
400
410
425
450
480
490
Generator
Rated output
8.4kw
10.5kw
12.0kw
14.0kw
16.0kw
20.0kw
Max. output
9.7kw
11.5kw
13.7kw
15.4kw
17.8kw
22.0kw
Frequency
50Hz
Phase
Single
Factor
CosΦ =1.0
Voltage Tegulation Syatem
AVR
Poles
2
Dirvetrain
Direct-coupled
Voltage
220v
Insulation
Stator & Rotor: F grade
Engine
Model
CZ380Q
CZ480Q
Speed
3000rpm
Type
Water cooled, 4 stroke, three cylinders
Water cooled, 4-stroke, four cylinders
Displacement
1357cc
1809cc
Starting system
Electric start
Oil consumption(1/h)
5.2
Fuel tank capacity(L)
Sound leveal [db(A)/7m]
76
77
78
79
80
80
