Vertical Electric Powered Steam Generator
Price: |
US $ 3200-3280/Piece |
Trade Terms: |
FOB,CFR,EXW |
Min Order: |
1/Set |
Pay Type: |
L/C,T/T,D/P |
Vertical Electric Powered Steam Generator:
1) Steam Capacity: 42--85Kg/h
2) Input Power: 30-60KW
3) Woring Pressure: 7-12.5bar
4) Voltage: 110-600V
Product Name: Small Electric Steam Boiler
I. Product Introduction:
"FUTURE" Small electric steam boiler is run by power energy, no noise, no pollution. Using high quality heating elements, with a lower surface heat load and higher thermal efficiency. This product adopts cabinet design style, elegant appearance, compact internal structure and it's ideal for saving space.
1. Small Input Power(36-60KW) with higher output(50-85Kg/h).
2. Use of Nichrome Heating Element, it ensures long-term effective operation of the boiler.
3. Mini Electric Steam Generator has a compact structure with fast heating speed, reaching to use pressure by several minutes.
4. Unique built-in steam-water separator solved a problem of steam with water which brought by similar products.
IDEAL FOR CLOTHES PRESSING, LAUNDRY, HOSPITAL, FOOD PROCESSING AND STEAM ROOM APPLICATIONS, etc...
II. Details of Electric Steam Boiler
1) Assembly
2. Would First-class Components & Parts(Only for reference):
3. Customer Using Site:
III. Technical Parameters:
Model |
LDR0.042-0.7 |
LDR0.05-0.7 |
LDR0.065-0.7 |
LDR0.075-0.7 |
LDR0.085-0.7 |
Item |
Unit |
Rated Steam Capacity |
Kg/h |
42 |
50 |
65 |
75 |
85 |
Rated Working Pressure |
Bar / Psig |
7 / 101 (Made to order) |
Saturated Steam Temperature |
°C |
171 |
Input Power |
KW |
30 |
36 |
48 |
54 |
60 |
Input Current |
A |
45 |
54 |
72 |
81 |
90 |
Power Source |
V/Hz |
380,50 (Made to order) |
Water Inlet |
DN |
15 |
15 |
20 |
20 |
25 |
Steam Outlet |
DN |
15 |
20 |
25 |
20 |
25 |
Blowdown Valve |
DN |
15 |
15 |
25 |
20 |
25 |
Safety Valve |
DN |
15 |
15 |
25 |
20 |
25 |
Overall Dimension(L*W*H) |
mm |
920×700×1200 |
960×750×1400 |
990×820×1590 |
Weight |
kg |
132 |
160 |
200 |
220 |
260 |
Prod Model: |
LDR Series |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Name: |
Electric Powered Steam Generator |
Steam Output: |
42, 50, 65, 75 and 85kg/H |
Input Power: |
30, 36, 48, 54 and 60kw |
Main Power Source: |
3p/220-600V/50-60Hz |
Working Pressure: |
7bar / 101psig |
Electrical Components: |
Schneider, Siemens, Omron, FUJI, LG |
Heating Elements: |
#321 Ss, Titanium Alloy |
Electric Control: |
Mechanical, PLC |
Thermal Efficiency: |
98% |
Lead Time: |
5-20days/Set |
Function: |
Steam Boilers |
Fuel: |
Electric Heating |
Usage: |
Industrial |
Pressure: |
Low Pressure |
Drum Placement: |
Vertical Boiler |
Media: |
Steam |
Installation: |
Packaged Boiler |
Water Circulation: |
Mixed Circulation |
Manufacturing Level: |
B |
Burning Style: |
None |
Structure: |
Tubular |
Zhangjiagang Future Boiler Manufacture Co., Ltd., is a National boiler manufacture license enterprise, which has the certified for the certificate of ISO9001: 2000 quality assurance system. Future Boiler specializes in Oil (Gas) Fired Steam Boiler, Electric Steam Boiler, Small Electric Steam Generator, Electric Hot Water Boiler, Oil(Gas) Fired Hot Water Boiler, Marine Boilers, Boiler Accessories & Auxiliary Machines, etc...We satisfy the requirements of different customers to a maximum extent. In the last few years, we brought products development and sales into the field of high-tech energy conservation and environmental protection.
The company enjoys a good reputation in domestic and abroad by the outstanding quality and consummation service, our products already exported to more than 50 countries and regions, including USA, Europe and other developed countries. Continues growing market needs numerous innovative product concepts.
"Chariness, Carefulness, Patience and Permanent fine quality" is our company's entrepreneurial spirit, which is embodied in our sustainable advancing pace, and in getting along with customers, partners, internal staff and competitors.
