CER 4heads Liner Weigher VFFS Packaging Line CP420BW
About the contract,we need to confirm the following details.Warmly Tips:
a). What do you want to pack?Pls give me the picture.
b). Bag size ( length and width).
c). Bag weight and shape.
d). Film material.
Features:
1. Mitsubishi PLC+ WEINVIEW HMI/Siemens PLC+HMI, Double/Three Servo motor unit is available;
2. Servo motor unit& Double belt unit film transport;
3. Auto program set-up, Photo sensor tracking mark, quick change former assembly;
4. Perfect weighing accuracy performance by multi-head weigher.
Applications:
Suitable to packaging the high accuracy and easy fragile material, such as: Puffy food, crispy rice, Potato Chips, Snacks, candy, pistachio, sugar, apple slices, dumpling, chocolate, pet food, small wares etc
The above whole system does consist of the following:
1. Single bucket elevator/Z bucket conveyor with vibrating feeder;
2.2/4heads Liner weigher;
3. Working platform;
4. VFFS Packaging machine;
5. Output conveyor
6. Optional: Metal detector, Check weigher, Rotary collecting table, Nitrogen Generator, Air compressor.
Specifications of the main packaging machine CP520:
| Model | CP420B |
| Capacity | Max 60 bags/min |
| Measuring range | Max2, 000ml |
| Bag model | Pillow bag |
| Bag size | L 100-350mm
W80-250mm |
| Film Width | Max 520mm |
| Control+HMI | PLC + Chinese/
English interface |
| Air consumption | 0.8Mps, 0.5m3/min |
| Power | 1Phase, 50Hz, AC 220V, /2.5KW |
| Optional functions | Gusset bag; Vacuum pulling film. |
| Dimension(LxWxH) | 1580x1120x1790mm |
| Weight | 650kg |
