Frequency: 50Hz/60Hz
Rated AC Voltage: 110, 115,120, 220,230,240, 110/220,115/230,120/240V (Single-phase)
380,400,415, 220/380, 230/400,240/415V (Three-phase)
Max. AC Output:
DV5000S: 4.6 kW (50Hz), 5.0 kW (60Hz)
Rated AC Output: DV3600S:
DV5000S: 4.2 kW (50Hz), 4.6 kW (60Hz)
Power Factor: 1.0 (Single Phases), 0.8 (Three Phase)
Engine Model: DV5000S: DV186
Engine Type: Single-cylinder, Vertical 4-stroke, Direct-injection, Air-cooled Diesel Engine,
Displacement: DV186: 406cc
Max. Output: DV186: 9.4hp/3600rpm
Fuel: Diesel Light Fuel
Fuel Tank Capacity: 16.0L
Continuous Operating Hours:
DV5000S: 11h(50Hz), 10h(60Hz)
Lube Oil: SAE 10-30W
Oil Capacity:
DV186: 1.65L
Ignition System: Direct Injection
Starting System: Electric Started
Operating Noise Level(7m): 70-72dB(A)
Product Dimension: 955x575x790mm
Carton Dimension: DV5000S: 955x575x790mm
Net Weight: DV5000S: 165kg
Gross Weight: DV5000S: 170kg
Container: DV5000S: 68units/20FT, 140unit/40FT, 140niuts/40HQ
Ningbo David Power Co., Ltd. is a leading manufacture specialized in engine, generator, engine pump and other power product.
It located at Ningbo City, near ShangHai in Zhejiang proveince. DAVID POWER reaches an annual production capability more than 200, 000sets of engine product.
David Power manage to deliver the superior quality products and service to every customer and company.
At DAVID we bring together technology and engineing to create solutions for the benefit of our customers.
