Type: Revolving Magnetic Field, Self-excitation, 2 Poles, Single/Three-phase
Voltage Regulator: Auto Regulating System
Frequency: 50Hz/60Hz
Rated AC Voltage: 110, 115, 120, 220, 230, 240, 110/220, 115/230, 120/240V (Single-phase)
380, 400, 415, 220/380, 230/400, 240/415V (Three-phase)
Max. AC Output: 5.5KW(50Hz), 6.5KW(60Hz)
Rated AC Output: 5.0KW(50Hz), 5.5KW(60Hz)
Power Factor: 1.0(Single Phases), 0.8(Three Phase)
Engine Model: DV186A
Engine Type: Single-cylinder, Vertical 4-stroke, Direct-injection, Air-cooled Diesel Engine,
Displacement: 418 cc.
Max. Output: 10.0/3600rpm
Fuel: Diesel Light Fuel
Fuel Tank Capacity: 16.0L
Continuous Operating Hours: 9h(50Hz), 8h(60Hz)
Lube Oil: SAE 10-30W
Oil Capacity: 1.65L
Ignition System: Direct Injection
Starting System: Electric Started
Operating Noise Level(7m): 70-72dB(A)
Oil Alert: Yes
Fuel Gauge: Yes
Voltmeter: Yes
Pilot Light: Yes
AC Circuit Breaker: Yes
AC Socket: Yes
Electric Starter: Yes
Dry Battery: Yes
DC Output: Yes (12V/8.3A)
DC Circuit Breaker: DC Fuse
4-wheel Dolly Kit: Yes
Voltage Switch: Yes (Only for Dual Voltage)
Product Dimension: 935x555x720mm
Carton Dimension: 955x575x790mm
Net Weight: 170kg
Gross Weight: 175kg
Container: 70units/20FT, 142unit/40FT, 142niuts/40HQ
Optional Features:
1. 3-phase is available.
2. ATS: Auto Transfer Switch
3. Remote Control Started
