Type: Revolving Magnetic Field, Self-excited, 2 Poles, Brushless, Single/Three-phase
Voltage Regulator: Auto Regulating System
Frequency: 50Hz/60Hz
Rated AC Voltage: 110,115,120, 220,230,240, 110/220,115/230,120/240V (Single-phase)
380,400,415, 220/380, 230/400,240/415V (Three-phase)
Max. AC Output: DV3600CL: 3.3KW/50Hz, 3.6KW/60Hz
Rated AC Output: DV3600CL: 3.0KW/50Hz, 3.3KW/60Hz
Engine Model: DV3600CL: DV178
Engine Type: Air-cooled, Single-cylinder, 4-stroke, Direct-injection Diesel.
Displacement:DV3600CL: 296cc.
Max. Output: DV2200CL: DV3600CL: 6.0hp/3600rpm
Fuel: Light Diesel
Fuel Tank Capacity: 12.5L
Continuous Operating Hours: DV3600CL: 12h/50Hz, 11h/60Hz
Lube Oil: SAE 10-30W
Oil Capacity: DV3600CL: 1.1L
Starting System: Recoil or Recoil/Electric
Operating Noise Level(7m): 78-80dB(A)
Product Dimension:DV3600CL: 680x455x545mm
Carton Dimension: DV3600CL: 695x470x560mm
Net Weight: DV3600CL: 70kg
Electric Started & Battery: plus 7kg
Gross Weight: DV3600CL: 73kg
Electric Started & Battery: plus 7kg
Container: DV3600CL: 144units/20FT, 292units/40FT, 292units/40HQ
