Voltage Regulator: Auto Regulating System
Frequency: 50Hz/60Hz
Rated AC Voltage: 110, 115,120, 220,230,240, 110/220,115/230,120/240V (Single-phase)
380,400,415, 220/380, 230/400,240/415V (Three-phase)
Max. AC Output: DV3600S: 3.3 kW(50Hz), 3.6 kW(60Hz)
Rated AC Output: DV3600S: 3.0 kW (50Hz), 3.3 kW (60Hz)
Power Factor: 1.0 (Single Phases), 0.8 (Three Phase)
Engine Model: DV3600S: DV178
Engine Type: Single-cylinder, Vertical 4-stroke, Direct-injection, Air-cooled Diesel Engine,
Displacement: DV178: 296cc
Max. Output: DV178: 6.0hp/3600rpm
Fuel: Diesel Light Fuel
Fuel Tank Capacity: 16.0L
Oil Capacity: DV178: 1.1L
Continuous Operating Hours: DV3600S: 15h(50Hz), 14h(60Hz)
Lube Oil: SAE 10-30W
Ignition System: Direct Injection
Starting System: Electric Started
Operating Noise Level(7m): 70-72dB(A)
Product Dimension: DV3600S: 855x555x720mm
Carton Dimension: DV3600S: 875x575x790mm
Net Weight: DV3600S: 130kg
Gross Weight: DV3600S: 135kg
Container: DV3600S: 76units/20FT, 156unit/40FT, 156units/40HQ
