Type: Revolving Magnetic Field, Self-excited, 2 Poles, Single/Three-phase
Voltage Regulator: Auto Regulating System
Frequency: 50Hz/60Hz
Max. AC Output: 2.8KW/50Hz, 3.0KW/60Hz
Rated AC Voltage: 110,115,120, 220,230,240, 110/220,115/230,120/240V (Single-phase)
380,400, 380/220, 400/230 (3-phase)
Rated AC Output: 2.5KW/50Hz, 2.7KW/60Hz
Engine Model: DP200
Engine Type: Air-cooled, Single-cylinder, 4-stroke,OHV, Gasoline.
Displacement: 196cc.
Max. Output: 6.5hp/3600rpm
Fuel: Unleaded gasoline
Fuel Tank Capacity: 15L
Continuous Operating Hours: 12h/50Hz, 11h/60Hz
Lube Oil: SAE 10-30W
Oil capacity: 0.65L
Starting System: Recoil or Recoil/Electric
Operating Noise Level(7m): 65-66dB(A)
Oil Alert: Yes
Fuel Gauge: Yes
Voltmeter: Yes
Pilot Light: Yes
AC Circuit Breaker: Yes
AC Socket: Yes
Electric Starter: Optional
Battery Tray Kit: Optional
DC Output: Yes 12V/8.3A
DC Circuit Breaker: DC Fuse
4-wheel Dolly Kit: Optional
Voltage Switch: Yes (Only for Dual Voltage Type)
Product Dimension: 590x430x440mm
Carton Dimension: 600x440x450mm
Net Weight: 43kg (Electric Started & Battery: plus 5kg)
Gross Weight: 45kg (Electric Started & Battery: plus 5kg)
Container: 240units/20FT, 480units/40FT, 570units/40HQ
NOTE: Item such as Electric started, Battery, 4-wheel kit and 3-phase are optional.
