Type: Revolving Magnetic Field, Self-excitation, 2 Poles, Brushless, Single/Three-phase
Voltage Regulator: Auto Regulating System
Frequency: 50Hz/60Hz
Max. AC Output: 5.5KW/50Hz, 6.5KW/60Hz
Rated AC Voltage: 110,115,120, 220,230,240, 110/220,115/230,120/240V (Single-phase)
380,400,415, 220/380, 230/400,240/415V (Three-phase)
Rated AC Output: 5.0KW/50Hz, 5.5KW/60Hz
Engine Model: DP390
Engine Type: Air-cooled, Single-cylinder, 4-stroke, OHV, Gasoline Engine
Displacement: 389cc.
Max. Output: 13.0hp/3600rpm
Fuel: Unleaded Gasoline
Fuel Tank Capacity: 25.0L
Continuous Operating Hours: 10h/50Hz, 9h/60Hz
Lube Oil: SAE 10-30W
Oil capacity: 1.4L
Ignition System: T.C.I
Starting System: Recoil or Recoil/Electric
Operating Noise Level(7m): 68-70dB(A)
Oil Alert: Yes
Fuel Gauge: Yes
Voltmeter: Yes
Pilot Light: Yes
AC Circuit Breaker: Yes
AC Socket: Yes (the socket type according to the order)
Electric Starter: Optional
Battery Tray Kit: Optional
DC Output: Yes 12V/8.3A
DC Circuit Breaker: DC Fuse
4-wheel Dolly Kit: Optional
Voltage Switch: Yes (Only for Dual Voltage Type)
Product Dimension: 685x485x550mm
Carton Dimension: 700x500x565mm
Net Weight: 85kg (Electric Started & Battery: plus 6kg)
Gross Weight: 88kg (Electric Started & Battery: plus 6kg)
Container: 136units/20FT, 280units/40FT, 280units/40HQ
NOTE: Item such as Electric started, Battery, 4-wheel kit and 3-phase are optional,
