Type: Revolving Magnetic Field, Self-excited, 2 Poles, Brushless, Single/Three-phase
Voltage Regulator: Auto Regulating System
Frequency: 50Hz/60Hz
Rated AC Voltage: 110, 115, 120, 220, 230, 240, 110/220, 115/230, 120/240V (Single-phase)
380, 400, 415, 220/380, 230/400, 240/415V (Three-phase)
Max. AC Output: DV5000CL: 4.6KW/50Hz, 5.0KW/60Hz
Rated AC Output: DV5000CL: 4.2KW/50Hz, 4.6KW/60Hz
Engine Model: DV5000CL: DV186
Engine Type: Air-cooled, Single-cylinder, 4-stroke, Direct-injection Diesel.
Displacement: DV5000CL: 406CC.
Max. Output: DV5000CL: 9.4HP/3600rpm
Fuel: Light Diesel
Fuel Tank Capacity: 12.5L
Continuous Operating Hours: DV5000CL: 9h/50Hz, 8h/60Hz
Lube Oil: SAE 10-30W
Oil Capacity: DV5000CL: 1.65L
Starting System: Recoil or Recoil/Electric
Operating Noise Level(7m): 78-80dB(A)
Product Dimension: DV5000CL: 740x475x590mm
Carton Dimension: DV5000CL: 755x490x605mm
Net Weight: DV5000CL: 88kg
Electric Started & Battery: Plus 7kg
Gross Weight: DV5000CL: 91kg
Electric Started & Battery: Plus 7kg
Container: DV5000CL: 99units/20FT, 207units/40FT, 276units/40HQ
Ningbo David Power Co., Ltd. is a leading manufacture specialized in engine, generator, engine pump and other power product.
It located at Ningbo City, near ShangHai in Zhejiang proveince. DAVID POWER reaches an annual production capability more than 200, 000sets of engine product.
David Power manage to deliver the superior quality products and service to every customer and company.
At DAVID we bring together technology and engineing to create solutions for the benefit of our customers.
