Type: Revolving Magnetic Field, Self-excited, 2 Poles, Brushless, Single/Three-phase
Voltage Regulator: Condenser (Three-phase: AVR)
Frequency: 50Hz/60Hz
Max. AC Output: 5.75KVA(50Hz), 6.25KVA(60Hz)
Rated AC Voltage: 110, 115, 120, 220, 230, 240, 110/220, 115/230, 120/240V (Single-phase)
380, 400, 415, 220/380, 230/400, 240/415V (Three-phase)
Rated AC Output: 5.25KVA(50Hz), 5.75KVA(60Hz)
Engine Model: DV186
Engine Type: Air-cooled, Single-cylinder, 4-stroke, Direct-injection Diesel.
Displacement: 406cc.
Max. Output: 10.0HP/3600rpm
Fuel: Light Diesel
Fuel Tank Capacity: 12.5L
Continuous Operating Hours: 8 h(50Hz), 7h(60Hz)
Lube Oil: SAE 10-30W
Oil capacity: 1.65L
Starting System: Recoil or Recoil/Electric
Operating Noise Level(7m): 70dB(A)(50Hz) 72dB(A)(60Hz)
Min. Fuel comsumption(g/kwh): 273.5
Oil Alert: Yes
Fuel Gauge: Yes
Voltmeter: Yes
Pilot Light: Yes
AC Circuit Breaker: Yes
A. V. R.: Condenser(Three-phase: AVR)
AC Socket: Yes
Electric Starter: Optional
Battery Tray Kit: Optional
DC Output: Yes 12V/8.3A
DC Circuit Breaker: DC Fuse
4-wheel Dolly Kit: Optional
Voltage Switch: Yes (Only for Dual Voltage Type)
Product Dimension: 740x475x590mm
Carton Dimension: 770x505x625mm
Net Weight: 88kg (E: 93)
Gross Weight: 91kg (E: 96)
Container: 99units/20FT, 207units/40FT, 276units/40HQ
NOTE: Item such as Electric started, Battery and 4-wheel kit, also the 3-phase are optional, need plus in prices.
DV6000CL: 99units/20FT, 207units/40FT, 276units/40HQ
