240W Mono Photovoltaic Modules (Model: BR-M240W)
Standard: TUV, IEC61215, CE & EN
Place of Origin: China
Solar cell spec: 125*125 Monocrystalline silicon solar cells
Specifications: Photovoltaic Modules with 240W maximum power
Max. System voltage: 1000V DC
Power tolerance: 0%-3%
Surface max. Load capacity: 70m/S(200KG/sq. M)
Photovoltaic Modules weight: 21.5KG
Photovoltaic Modules Dimensions: 1580mm*1060mm*50mm
Photovoltaic Modules Electrical Characteristics:
Open circuit voltage(V): 59.5V
Short circuit current(A): 5.50A
Max. Power voltage(V): 46.9V
Max. Power current(A): 5.11A
Module efficiency(%): ≥ 16.0%
FF(%): 70-72%
Conditions (STD):
Irradiance: 1000W/M2
Temperature: 25° C
Operating temperature: -40° C to +80° C
Storage temperature: -40° C to +80° C
Packing: 2 PCS/CTN
Junction boxTUV Certified, MC4 Connector, Water-proof.
Glass: High-Transmission, Low iron tempered glass.
Limited Warranty: Workmanship for 5 years, 90% of minimum power output over 12 years, 80% over 20 years.
(Lifespan: 20-25 Years)
20'GP: 14Pallets / 316PCS
40'HQ: 28Pallets / 756PCS
Limited Warranty: Workmanship for 5 years,90% of minimum power output over 12 years,80% over 20 years. The solar panels are manufactured in according to the IEC61215 Standards.
Lifespan:20-25 Years
BR SOLAR Marked Main & Best Competitive Products:
| A.) | Solar Street Lights & LED Street Lighting 15W to 120W |
| B.) | 10W-240W LED Street Lights and LED Fixture |
| C.) | Solar Garden Lights & Solar Landscape Lights 5W to 30W |
| D.) | Solar Panels & Solar Modules 5W to 300W Poly & Mono Silicon |
| E.) | Solar Battery 4.5Ah/12V~250Ah/12V and 200AH/2V-3000AH/2V |
| F.) | Solar Home Lighting System and Solar Home System 5W to 5000W With LED Bulbs + Fan + TV + Fridge + USB Charging Phone Function, Including AC and DC Design |
| G.) | Solar Controllers: 5A to 60A/12V Or 24V Or 48V IP 65 IP68 Rating |
More Photovoltaic Modules Information and Price, call or mail us please.
Yangzhou Bright Solar Solutions Co., Ltd., Established in 1997, an ISO 9001: 2000, TUV, IEC, CE&EN, RoHS, SONCAP, CCPIT, SASO and CCC approved manufacturer.
Overseas Exploration and Popularity:
We had successfully sold our solar street lights and solar panels to overseas markets more than 50 Countries such as the USA, Canada, UK, Greece, France, Italy, Australia, Turkey, Jordan, Saudi Arabia, Iraq, UAE, India, Philippines, Pakistan, Cambodia, Taiwan, Nigeria, Ghana, Congo, South Africa, Mexico, Haiti, etc.
For the Future:
With advanced manufacturing & testing equipments, our factories are growing better and better. We hope to cooperate with more partners and distributors to develop more business to create prosperous win-win partnerships. OEM is available. Welcome your inquiry mail or call.
Main Products:
Solar Street Lights & Solar Street Lighting & LED Solar Street Lighting;
Solar Garden Lights & Solar Landscape Lights;
Solar Panel & Solar Modules.
Small Solar Home System & Solar Home Kits.
Attention: We are good at
1: Designing, producing, installing solar 10W-120W Solar LED street lights
2: Designing, producing 10W-240W LED Lamp for outdoor street and road using.
3: Producing solar panel below 310W
4. Solar Battery 7Ah-300Ah/12V
5. Solar Home Kits 3W-5000W System
OEM Service for solar lighting and PV panel is available.
Welcome your inquiry of solar outdoor lights and solar home lights.
