Portable Type Integrated Model Br5w-4.5ah Solar Home Lighting Kits
| Price: |
US $ 22-380/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
100/Set |
| Pay Type: |
L/C,T/T,D/P,Paypal,Money Gram |
Selling Topic:Portable Type Integrated Model BR5W-4.5Ah Solar Home Lighting Kits.Operation Description For Solar Home Kits.Please make the battery fully charged before using it for the first time, when all indicator lights are always being on. it shows the charging is completed .How To Using this model solar lighting kits.Plug the bulb cable into the socket which marked ,and turn on or off the light by touching the power switch gently.Popular Model Of Solar Home Lights and Solar Home Kits.
The system allocates high capacity battery, lighting time when fully charged please see the chart as below.| Quantity of bulbs | Lighting time when fully charged |
| 1 PC | 30 hours |
| 2 PCs | 15 hours |
The system choose high bright bulbs with 130LM above, equal to 25W incandescent lamp.Battery capacity indicator:3 indicator lights being on: 50~100%2 indicator lights being on: 20~50%1 indicator light being on: <20% warning: THE bulbs is super bright led bulbs, PLEASE AVOID looking AT it DIRECTLY when ITS lighting. How to charge this Solar Home Lights. Charge the system by using solar panel, you can refer to the below steps:1. Place the Solar Panel in the sun where can receive the strongest sunlight2. Plug the panel cable into the socket which marked, when indicator light twinkles slowly, that means charging normally.In order to get higher charging efficiency, may use the below methods:1. Place the solar panel towards the sun to avoid covering by shadow 2. Wipe the panel surface by using the wet cloth regularly to avoid covering by dust or blot.3. Place the system box where is shady and cool when charging so that the charge efficiency can be increased.4. MCU controls charging intelligently, do not go out without pulling out the solar panels.Popular Model Of Solar Home Lighting Kits
How to charge the Mobile phone.Operation steps :1. Plug the USB into the port which marked 2.Connect the mobile phone through the connector.3. Also can charge MP3, MP4, Digital Camera, etcSolar Home Kits Specification| Size of Controlling Box | 126*57*185mm 0.94kg |
| Solar Panel | 5W/9V
Vmp: 8.7V; lmp:0.57A; Voc:10.8V; Isc0.61A Dimension 220*185*18mm
Weight:0.52kg |
| Panel Cable | 3M Length |
| Battery | 6V/4.5AH Lead-acid |
| Bulbs | 1.3W 0.12kg*2 |
| Color Temperature of Bulbs | 6000-6500K |
| Bulb Cable | 3M Length With Switch |
| USB Output | 5V/500ma |
| Color Box Size | 230*85*190mm 0.12kg |
| Net Weight of System | 1.70kg |
| Gross Weight of System | 1.82kg |
| Carton Size | 480*280*410mm (12PCs) |
| Net weight | 20.40kg |
| Gross Weight | 21.84kg |
Popular Model Of Solar Home Kits
Battery maintenance and using skill The system uses a 6V 4.5Ah lead-acid Maintenance- Free rechargeable battery In order to keep the longest lifespan. 1. Please don't keep the battery in over- discharged status for a long time.2. Please charge the battery at least one time every 3 months, even you don't use it .3. When replace battery, please only use 6V lead-acid battery, and under guiding by professional person.BR SOLAR Brief Introduction: Yangzhou Bright Solar Solutions Co., Ltd., Established in 1997, an ISO 9001: 2000,
TUV, IEC, CE&EN, RoHS, SONCAP CCPIT,IES, FCC, PVOC,SASO and CCC approved manufacturer.
Overseas Exploration and Popularity:
We had successfully sold our Solar Street Lights and Solar Home Kits to overseas markets more than 50 Countries such as the USA, UK, Canada, Germany, Spain, Greece, Italy, Sweden, France, Portugal, Cyprus, Romania, Croatia, Middle East, New Zealand, Fiji, Norway, Belgium, France, Italy, Australia, Turkey, Jordan, Iraq, UAE, India, Pakistan, Bangladesh, Qatar, Yemen, Singapore, Philippines, Cambodia, Nigeria, Congo, Mexico, etc. BR SOLAR Marked Main & Best Competitive Products:A.) Solar Street Lights & LED Street Lighting 15W to 120W;
B.) Solar Garden Lights & Solar Landscape Lights 5W to 30W;
C.) Solar Home Lighting System and Solar Home Kits : 5W to 5000W With LED Bulbs + Fan + TV + Fridge + USB Charging Phone Function, Including AC and DC Design;
D.) Solar Battery: 4.5Ah to 250Ah/12V, 200Ah to 3000Ah/2V;
E.) Solar Panels & Solar Modules 5W to 300W Poly & Mono ;
F.) Solar Controllers: 5A to 60A/12V Or 24V Or 48V IP 65 IP68 Rating;Pls Enter www.cnsolarlight.com or http://light1978.en.made-in-china.com for more information about BR SOLAR marked Hot Sale No. 1 Ranking Manufacturer Hot-Sold Portable Type Integrated Model Br5w-4.5ah Solar Home Lighting Kits.
Pls send us more details about your purchasing,
Thank you for your time and attention.
| Prod Model: |
BR5W-4.5AH Solar Home Lighting Kits |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Application: |
Solar Home Lighting Kits |
| Home Solar System: |
Solar Lighting Kits |
| Solar Panel: |
5 W |
| Solar Battery: |
6V/4.5ah Lead-Acid |
| Bulbs: |
1.3W 0.12kg*2 |
| USB Output: |
5V/500mA |
| Color Box Size: |
230*85*190mm 0.12kg |
| Carton Size: |
480*280*410mm (12PCS) |
| Warranty: |
2 Years |
| Can Changed: |
Phone,MP3, MP4,Radio |
| System: |
Off-Grid system |
| Power: |
5W |
Yangzhou Bright Solar Solutions Co., Ltd., Established in 1997, an ISO 9001: 2000, TUV, IEC, CE&EN, RoHS, SONCAP, CCPIT, SASO and CCC approved manufacturer.
Overseas Exploration and Popularity:
We had successfully sold our solar street lights and solar panels to overseas markets more than 50 Countries such as the USA, Canada, UK, Greece, France, Italy, Australia, Turkey, Jordan, Saudi Arabia, Iraq, UAE, India, Philippines, Pakistan, Cambodia, Taiwan, Nigeria, Ghana, Congo, South Africa, Mexico, Haiti, etc.
For the Future:
With advanced manufacturing & testing equipments, our factories are growing better and better. We hope to cooperate with more partners and distributors to develop more business to create prosperous win-win partnerships. OEM is available. Welcome your inquiry mail or call.
Main Products:
Solar Street Lights & Solar Street Lighting & LED Solar Street Lighting;
Solar Garden Lights & Solar Landscape Lights;
Solar Panel & Solar Modules.
Small Solar Home System & Solar Home Kits.
Attention: We are good at
1: Designing, producing, installing solar 10W-120W Solar LED street lights
2: Designing, producing 10W-240W LED Lamp for outdoor street and road using.
3: Producing solar panel below 310W
4. Solar Battery 7Ah-300Ah/12V
5. Solar Home Kits 3W-5000W System
OEM Service for solar lighting and PV panel is available.
Welcome your inquiry of solar outdoor lights and solar home lights.
