Steam turbine generator type: Turbine generator; Gas turbine; Turbine engine; Steam turbine generators; 10MW20MW30MW40MW50MW60MW100MW steam turbine generator;
Multi-stage
Single-stage
We can design steam turbine according to your need.
Features:
1. Single-stage and multistage steam turbine are optional. Capacity from 100KW to 50MW. Applicable for various industries or conditions.
2. Reliabe performance. Easy operation.
3. Single-stage has a simple structure, therefore it is convenient to install and the adaptability is well.
4. Adopt DEH governing system or full hydraulic governing system. Most used for driving pump or other small capacity equipments.
5. Security system with complete functions.
Parameters:
Model Code Capacity
(MW) Inlet Exhaust
Pressure
(MPa) Consumption
(kg/kw. H) Weight
(t) Overall
Dimensions
LxWxH(mm) Speed
(r/min)
Pressure
(MPa) Temp
() Flow
(t/h)
5120x4120x2650 3000
B15-3.43/0.294 N3641B 15 3.43 435 117 0.294 7.80 42 4825x4120x2650 3000
B15-4.90/(0.981)/0.294 N651B 15 4.9 435 111 0.294 7.40 42 5000x4120x2650 3000
B25-8.83/0.981 N774B 25 8.83 535 216 0.981 8.64 62.8 5940x3515x3295 3000
B25-8.83/1.2 N775B 25 8.83 535 236 1.2 9.44 62.8 5940x3515x3295 3000
B50-8.83/0.294 N871B 50 8.83 535 367 0.294 7.34 104 7795x3603x3505 3000
B50-8.83/1.28 N872B 50 8.83 535 425 1.28 8.50 76 7510x3390x3480 3000
Founded in 2013 and located inShenzhen economic development zone, SHENGZHEN SHI QIANHAI ZHONGSHA PETROCHEMICAL INDUSTRY TRADE CO.,LTD Covers an area of 400, 000 square meters, with 160, 000 square meters area of structure. Currently, there is a technological R&D and engineering service team of more than one hundred talents, leading by doctors, senior engineers and engineers.
The technological R&D ability and production capacity have reached state-of-the-art level. At present there are 39 departments altogether, including departments for home and abroad sale, technological research and development, quality test, process control, equipment, supply, procurement, financing, auditing, human resources, rear services, 8 manufacture workshops and after- sale service etc.
