31000KW2000KW 3MW4MW5MW6MW8MWgas turbine/ge gas turbine; Gas turbines/gas turbine generators; Gas turbine power plant/gas turbine; Gas turbine engine/gas turbine generator; Micro gas turbine/gas turbine engines; Coal gas generator. Coal fire plants
We can design steam turbine according to your need.
Features:
1. Pressure from 0.14 MPa to 14 Mpa.
2. According to the user's requirement to design un-controlled extraction steam type to bleed steam for industry.
3. According to capacity and the user's requirement to design layout, single-tier or double-tier.
4. Adopt DEH or full hydraulic governing system.
5. Security system with complete functions.
Model |
Code |
Capacity
(MW) |
Speed
(r/min) |
Inlet |
Consumption
(kg/kw. h) |
Exhaust
Pressure
(MPa) |
Weight
(t) |
Overall
Dimensions
LxWxH(mm) |
Pressure
(MPa) |
Temp
() |
Flow
(t/h) |
N0.5-1.27 |
N123 |
0.3-0.5 |
6500 |
1.27-1.5 |
250-300 |
2.4-3.6 |
6.3-7.6 |
0.008 |
|
|
N0.66-1.6 |
N122 |
0.66 |
5600 |
1.6 |
280 |
4.45 |
6.74 |
0.008 |
12 |
3655x2200x1950 |
N0.75-1.27 |
N121 |
0.75 |
6500 |
1.27 |
340 |
4.4 |
5.87 |
0.0086 |
14 |
3630x2250x2120 |
N1.1-2.3 |
N232 |
1.1 |
6500 |
2.3 |
305 |
7.1 |
6.45 |
0.008 |
10 |
2755x2050x1943 |
N1.1-3.92 |
N25 |
1.1 |
6500 |
3.92 |
320 |
6.8 |
6.18 |
0.013 |
10 |
2755x2050x1943 |
N1.5-1.27 |
N221 |
1.5 |
5600 |
1.27 |
300 |
9.49 |
6.33 |
0.0063 |
12.1 |
3655x2200x1950 |
N1.5-1.27 |
N22 |
1.5 |
5600 |
1.27 |
340 |
8.75 |
5.83 |
0.0103 |
25 |
4112x2652x2515 |
N1.5-2.35 |
N23 |
1.5 |
6500 |
2.35 |
390 |
8.41 |
5.61 |
0.0103 |
17 |
3655x2240x2115 |
N1.5-2.35 |
N231 |
1.5 |
6500 |
2.35 |
390 |
8.27 |
5.51 |
0.009 |
12.1 |
3655x2200x1950 |
N1.5-3.43 |
N24 |
1.5 |
6500 |
3.43 |
435 |
7.32 |
4.88 |
0.008 |
12.1 |
3655x2200x1950 |
N1.6-2.35 |
N232 |
1.6 |
6500 |
2.35 |
380 |
8.51 |
5.32 |
0.0103 |
8.5 |
2750x2020x1945 |
N1.9-2.35 |
N233 |
1.9 |
4800 |
2.35 |
305 |
11.1 |
5.84 |
0.008 |
25 |
4110x2655x2510 |
N3-1.25 |
N331 |
3 |
5600 |
1.25 |
310 |
19 |
6.33 |
0.01 |
25 |
4110x2655x2510 |
N3-2.35 |
N33 |
3 |
5600 |
2.35 |
390 |
16 |
5.33 |
0.0103 |
25 |
4110x2655x2510 |
N3-2.35 |
N333 |
3 |
5600 |
2.35 |
390 |
16 |
5.33 |
0.0103 |
25 |
4245x2440x1960 |
N3-2.35 |
N335 |
3 |
5600 |
2.35 |
300 |
17.45 |
5.82 |
0.0105 |
25.3 |
4230x2440x1955 |
N3-3.43 |
N34 |
3 |
5600 |
3.43 |
435 |
13.3 |
4.43 |
0.0103 |
25 |
4440x2400x1965 |
N3-4.9 |
N35 |
3 |
6500 |
4.9 |
470 |
13.7 |
4.57 |
0.008 |
|
|
N4-2.35 |
N431 |
4 |
3000 |
2.35 |
390 |
20 |
5.00 |
0.0062 |
17 |
3750x2295x2825 |
N4-3.43 |
N441 |
4 |
5600 |
3.43 |
435 |
19.6 |
4.90 |
0.012 |
25 |
4440x2400x1965 |
N4.5-4 |
N442 |
4.5 |
3000 |
4 |
435 |
21.1 |
4.69 |
|
|
|
N5-2.35 |
N432 |
5 |
3000 |
2.35 |
390 |
26 |
5.20 |
0.0098 |
16.5 |
3750x3150x2040 |
N5-3.43 |
N442 |
5 |
3000 |
3.43 |
435 |
24.7 |
4.94 |
0.0087 |
17 |
3750x3150x2040 |
N6-2.35 |
N43 |
6 |
3000 |
2.35 |
390 |
30.4 |
5.07 |
0.0098 |
16.5 |
3750x3150x2040 |
N6-3.43 |
N44 |
6 |
3000 |
3.43 |
435 |
27 |
4.50 |
0.0081 |
16.5 |
3750x2295x2825 |
N6.3-3.82 |
N45 |
6.3 |
3000 |
3.82 |
385 |
33 |
5.24 |
0.008 |
|
|
N7-3.43 |
N542 |
7 |
3000 |
3.43 |
435 |
31.11 |
4.44 |
0.011 |
16.8 |
3730x3150x2040 |
N9-3.43 |
N544 |
9 |
3000 |
3.43 |
435 |
41.2 |
4.58 |
0.0061 |
|
|
N12-3.43 |
N542 |
12 |
3000 |
3.43 |
435 |
53 |
4.42 |
0.0075 |
47 |
5500x3100x3255 |
N12-3.92 |
N55 |
12 |
3000 |
3.92 |
397 |
50.6 |
4.22 |
0.0049 |
55 |
5840x4700x2855 |
N15-3.43 |
N64 |
15 |
3000 |
3.43 |
435 |
68.2 |
4.55 |
0.0067 |
49.5 |
5550x3120x3250 |
N15-4.90 |
N65 |
15 |
3000 |
4.9 |
435 |
61 |
4.07 |
0.0052 |
49.5 |
5630x3120x2350 |
N18-3.43 |
N74 |
18 |
3000 |
3.43 |
435 |
82.8 |
4.60 |
0.0104 |
50 |
5550x3120x3250 |
N18-8.83 |
|
18 |
3000 |
8.83 |
535 |
70.5 |
3.92 |
0.0049 |
|
|
N25-3.43 |
N84 |
25 |
3000 |
3.43 |
435 |
110 |
4.40 |
0.0065 |
60 |
6765x5000x2920 |
N25-8.83 |
N85 |
25 |
3000 |
8.83 |
500 |
104.5 |
4.18 |
0.0041 |
130 |
7200x4400x3300 |
