Performance characteristic:
*Mono/polycrystalline soalr panel constitute the soalr square array in series or parallel.
*Highly-efficient intelligent automatically solar charge or discharge controller, Multistage PWM charging mode and MPPT tracking technology, take advantage of the solar source array efficiency completely, all-directional protect the battery and prolong life.
*Deep circulating battery system, get more power effectively
*Sine wave inverter, make the solar power system connect with public, complement each other
*Simple, quakeproof, anticorrosion bracket, Install conveniently.
Warranty:
*2years maintenance-free for the whole set.
Application:
*For using widely communication equipment, rural electrification, movable leisure house car, school, hospital, ect
*The working duration shall be varied in different regions.
|
SW-SPS1.5KW
|
SW-SPS1.8KW
|
SW-SPS2.3KW
|
Power of solar panel
|
1500W
|
1800W
|
2300W
|
Capacity of battery
|
48V/200AH
|
48V/300AH
|
48V/400AH
|
Controller
|
48V/ 40A
|
48V/ 45A
|
48V/ 45A
|
Inverter
|
2KVA
|
2KVA
|
3KVA
|
Output voltage
|
DC 48V/AC 220V
|
DC 48V/ AC 220V
|
DC 48V/AC 220V
|
Working duration
|
Daily electricity consumption can be 4.8KWh~8.0KWh, working duration will be different for varied loads.
|
|
Opearating temperature |
-20 º C ~+65 º C |
|
Battery breaker rating |
50A |
50A |
80A |
|
PV cables |
1*4mm 2, length 30 meters |
1*4mm 2, length 45 meters |
1*4mm 2, length 60 meters |
|
Battery charge cables |
1*10mm 2, Length 20 meters |
1*16mm 2, Length 20 meters |
|
Inverter input cables |
1*16mm 2, Legth 10 meters |
1*16mm 2, Legth 12 meters |
1*25mm 2, Legth 12 meters |
Dongguan SunWorth Solar Energy Co., Ltd. is a leading solar energy company and a middle-sized vertically integrated photovoltaic manufacturers. We develop, manufacture and sell solar panels, Solar Power Systems, Solar lights and other green energy equipments to a wide range of markets, including Africa, Southeast Asia and Middle East. And also we focus on developing market in Europe like France, Italy and the United States from now...
Located in World's manufacturing workshop-DONGGUAN, Sunworth occupies 6000 square meters courtyard-style factory and employs more than 200 skilled workers. We utilize advanced technology and good management to produce high-quality products with competitive cost structures.
We aspire to be socially and environmentally responsible in every decision we make and every product we supply. As a undertaker in sustainable energy solutions, we are striving to aim the goal"endless sunshine to share; Endless value to discover. "we are looking forward to establishing long-term business relationship with clients all over the world.
