Huizhou V-Way Energy Technlogy located in Shenzhen guangming, is one of HuiZhou v-way Energy Technology Co., Ltd. Production Base. We are specialized in research, manufacture and sale of Monocrystalline, Polycrystalline, Amorphous solar module and Solar Power(PV) System, Solar street light system.
Technical parameters
VW-P1000-A
VW-P1000-B
Output capacity
150VA
150VA
Output waveform
Modified wave
Modified wave
Output current
0.68A
0.68A
Precision of output voltage
220±3%
220±3%
Precision of output frequency
50±3HZ
50±3HZ
Power element
1
1
Overload ability
120%,30(seconds)
120%,30(seconds)
Work efficiency
More than 90%
More than 90%
Output voltage
AC220V
AC220V
Output frequency
50HZ
50HZ
Output power of solar panle
500W
1000W
Max output current of solar panle
14.3A
28.6A
Battery capacity
300AH
600AH
Battery voltage
24V
24V
Best output power everyday
1884WH
3768WH
The maximum continuous output power
7200WH
14400WH
Size of host case
650X540X1170mm
690X650X1275mm
Size of solar panel
1250X4050X35mm
2504X4050X35mm
Volume
0.82m3
1.6m3
Weight
336KG
672KG
Price
20130 RMB/ 2960 USD
39440 RMB/ 5800 USD
Huizhou V-Way Energy Technlogy located in Shenzhen guangming, is one of HuiZhou v-way Energy Technology Co., Ltd. Production Base. We are specialized in research, manufacture and sale of Monocrystalline, Polycrystalline, Amorphous solar module and Solar Power(PV) System, Solar street light system. The production base established in 2003, the first factory takes area 3600 square meter, and the second factory area which on construction, is planed to be reach 6000 square meter. There are 110 technicians in the workshop, 35 administrators and salesman, and 22 in the research team. What's more, there are 13 guys that have the intermediate and senior technical title. At present solar module production capacity is 100MW, solar power system production capacity is 1 million sets by one year. Products are mainly exported to Spain, France, Germany, Italy, Australia, Japan, Korea and African countries. Our products are especially suitable for islands, mountains, deserts, Areas without electricity and the lack of electricity.
In order to keep our vitality and competitive advantage on international market, we have strict controlled for the product quality with the policy of quality. Adhering to the "quality-oriented, control and orderly, continuous improvement, customer satisfaction, " the quality policy, strict accordance with ISO, CE, IEC, and TUV and other international standards for production. Has always been to provide customers with high-quality products and services.
Today, the increasingly serious energy crisis and the greenhouse effect, the development of green energy has become the theme of the times, Solar energy as a clean, sustainable energy solutions, in the twenty-first century as a progressive alternative energy. We will meet the requirements of the times, Efforts to promote and innovate green energy, efforts to improve the living environment of human future.
