| Prod Model: |
3D100 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Number Of Blade: |
Three Blade |
| Rotating Shaft: |
Horizontal |
| Stress Way Of Blade: |
Fluid Dynamic |
Product Description
Our product' superiority is: Unique 3D structure, low noise, low rotary speed, wide working speed range, durable and suitable for the working and living Environment.
Specifications
Nominal power out: 3.5KW
Wind turbine weight: 300KG
Rotor diameter: 4M
Swept area: 12.6m2
Type: HAWT
Blades: 3
Blades length: 2.7M
Nominal rpm: 125rpm
Work rpm: 40-350rpm
Orientation: Self oriented(no rudder)
Nominal wind speed: 2.5-35m/s
Survival wind speed: 50m/s
On grid: Swt+controller box+rectifier+inverter+isolation transformer
Off grid: Swt+controller box+rectifier+battery+inverter+fuse box
Sound level: <35dB at 12m/s
Color: White(other color available)
Overspeed protection: Electrical control
Service life: 20-30year
Zhangzhou NHEOLIS technology Co., Ltd, is a joint venture of ximen kehua hengsheng Co., Ltd and nheolis sas in France. The company currently concentrates on the research and manufacturing of small and medium wind generators and brings in patented technology from the nheolis France. Our products are mainly for the home or commercial use.
