Cooling Method:
Water Cooling
Stroke:
Four Stroke
Installation Method:
Fixed
Type:
Self-Starting Diesel Generator
Output Type:
AC Three Phase
Product Description
Mtu Diesel Generator Set (BMX1760)
MTU GENERATING SET, generator set, genset:
Genset model: BMX1760 1. Mtu generaoting set Continuous Output 1600KW / 2000kVA Standby Output 1760KW /2200kVA Rated Power Factor COSΦ =0.8(lagged) Rated Output Voltage 400V/230V(400-10000V can be reached) Rated Current(Continuous/Standby) 2886A/3175A Rated Speed 1500rpm Rated Frequency 50Hz Starting Control Method Auto Start/Handle Start Dimension(mm) 4750*1670*2380 Genset Weight(KG) 12430kg
Steady State Voltage Adjustment(%) ≤ +/-1 Voltage Fluctuation(%) ≤ +/-0.5 Transient State Voltage Adjustment(%) +20~-15 Voltage Stable Time(s) ≤ 1 Steady State Frequency Adjustment(%) ≤ +/-1 Frequency Fluctuation(%) ≤ +/-0.5 Transient State Frequency Adjustment(%) +10~-7 Frequency Stable Time(s) ≤ 3 Fuel Consumption(100% Load)(g/kwh) 192 g/kwh Noise(LP7m) 96dB(A)
2. Engine Specification Brand MTU Model No. 16V4000G623 No. Of Cylinder 16 Bore*Stroke 170*210 mm Starting Method 24V DC Voltage Bearing Starting Motor Cooling Method Close Circuit Water Cooling Oil-supply Method Electrical Injection Speed-adjustment Method Electronic Governing Aspiration Turbocharged Inter-cooled Speed 1500rpm
3. Alternator Brand Marathon Model No. 744RSL4054 Rated Power/Capacity 1540KW / 1925kVA Rated Voltage 400V/230V Output Factor COSΦ =0.8(lagged) Insulation Class H Class Protection Class IP23 Wiring Methods 3 Phases and 4 Wires Voltage Adjustment Methods DVR Output Frequency 50Hz
4. Control System Brand DeepSea From England Model Deepsea 7320
BS POWER DIESEL GENERATOR SET
50HZ 1500rpm 400/230V
MTU MARATHON
Genset Model
KW/KVA
KW/KVA
ENGINE MODEL
Cyl.(L)
Displacement (L)
Alternator Model (Marathon)
Fuel cons.100% (g/kw.h)
Net weight (kg)
Dimensions (L x W x H) MM
Prime power
standby power
Open Type
BMX270
240/300
270/338
6R1600G70F
6R
10.5
MP-240-4
201
2500
2800×1150×1650
BMX350
320/400
350/438
8V1600G70F
8V
14
MP-320-4
191
3450
2980×1350×1760
BMX400
360/450
400/500
10V1600G40F
10V
17.5
MP-350-4
191
3880
3220×1350×1850
BMX440
400/500
440/550
10V1600G50F
10V
17.5
MP-400-4
190
4000
3320×1350×1850
BMX520
480/600
520/650
12V1600G40F
12V
21
MP-480-4
195
4350
3500×1350×1850
BMX570
520/650
570/713
12V2000G25
12V
23.88
MX-560-4
203
6800
4200×1650×2280
BMX704
640/800
704/880
12V2000G65
12V
23.88
MX-630-4
202
6800
4200×1650×2280
BMX800
720/900
800/1000
16V2000G25
16V
31.84
MX-750-4
198
7700
4500×2000×2300
BMX880
800/1000
880/1100
16V2000G65
16V
31.84
MX-850-4
198
7800
4500×2000×2300
BMX1000
900/1125
1000/1250
18V2000G65
18V
35.82
MX-1030-4
202
8800
4750×2000×2380
BMX1100
1000/1250
1100/1375
12V4000G21R
12V
48.7
MX-1030-4
198
11000
6150×2150×2400
BMX1250
1120/1400
1250/1563
12V4000G23R
12V
48.7
MX-1240-4
198
12000
6150×2150×2400
BMX1450
1300/1625
1450/1813
12V4000G23
12V
57.24
MX-1350-4
189
13500
6150×2150×2400
BMX1600
1450/1812
1600/2000
12V4000G63
12V
57.24
MX-1540-4
193
14000
6150×2150×2400
BMX1760
1600/2000
1760/2200
16V4000G23
16V
76.32
MX-1600-4
193
17000
6500×2600×2500
BMX2000
1800/2250
2000/2500
16V4000G63
16V
76.32
MX-1800-4
191
17000
6550×2600×2500
Guangdong Binshi Power Technology Co., Ltd is one of the leading manufacturers of diesel and gas generator sets (generator, genset, diesel generator, power generator, silent generator, generating set, power generation). With years' professional experience in generator set design, manufacturing, sale and service, BS Power has won good reputation both at home and abroad.
BS Power has built a number of production bases and service centers across the country. Among them, the South China production base and after-sales service center which is located in Dongguan-the famous manufacturing city in the world, covering an area of 8, 000 square meters, owns more than 100 employees, in which 58 percent is engineering technicians, and has numbers of senior engineers. BS Power is people-oriented, creating the best technical management, marketing and planning talents. With abundant resources and innovative research capabilities, BS Power has established a research and development center with famous domestic universities.
In order to improve BS Power's production and technology capability. The second production base, which is located in Hubei Province with the total investment of 7, 000 million yuan, covering an area of 35, 000 square meters, has been put into production.
BS Power has established long-term close partnership with the world famous generator manufactures, such as Cummins in USA, Perkins in UK, MTU and Deutz in Germany, Doosan in Korea, and the genset is equipped with the famous alternator manufactures, like Marathon (USA), Leroy-somer(France) and Engga(UK). Meanwhile, BS Power has achieved ISO9001: 2008 Quality Certification System and ISO14001: 2004 Environmental Management System.
BS Power sincerely wishes to cooperate with distributors of gensets worldwide to expand its high-quality products in your market to reach the win-win goal in the future. Information about BS Power(manufacturer), products will be offered on your request.
