Product Description
1. Directly connected to the solar panels (do not need to connect the battery)
2. AC 0 angle with high precision auto-detection
3. Automatic Sensing Function Solar Luminosity
4. Constant Current, Constant Power
5. Automatically Shut Down When The Power Output Of a Fault
6. Stack Multiple Machines
7. High-Frequency High Conversion Rate
Grid-series models
200W
300W
400W
500W
600W
800W
1000W
Recommend use solar panels
320Wp
420Wp
520Wp
620Wp
720Wp
1050Wp
1250Wp
DC Maximum Input Power
300W
400W
500W
600W
700W
900W
1200W
DC maximum voltage
VpvDC30.2VDC
DC voltage range
Vpv 10.5V~28VDC
Maximum output power factor
99%
Maximum input current
15A
20A
25A
30A
40A
45A
65A
AC output power
200W
300W
400W
500W
600W
800W
1000W
AC maximum output power
200W
300W
400W
500W
600W
1000W
Anti-voltage protection
Fuse
AC standard voltage range
90V-140/180~260VAC
AC frequency range
55Hz~63Hz/ 45Hz-53Hz
Output current total
harmonic distortion
THDIAC <5%
Phase
<1%
Islanding protection
VAC;f AC
Output short circuit protection
Current-limiting
Show
LED
Standby Power
<2W
Night Power
<1W
Ambient temperature range
-25 ~60
Humidity
0~99%(Indoor Type Design)
Waterproof
Indoor Type Design
Electromagnetic Compatibility
EN50081.part1 EN50082.part1
Power System Disturbance
EN61000-3-2 EN60950-1
Network test
DIN VDE 1026
