| Price: | Negotiable/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T,Western Union |
| Prod Model: | HQS300GF |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Rated Power: | 300kw 375kVA |
| Rated Voltage: | 415/240V,400/230V,380/230V,etc |
| Rated Current: | 540A |
| Certificates: | CE, ISO |
| Global Warranty: | 12 Months Warranty |
| Options: | Open Type /Silent Type |
| Unique Options: | Trailer / Synchronization System |
| Base Fuel Tank Capacity: | Enough for 8-10 Hours Genset |
| Alternator: | Stamford / Leroy Somer |
| Engine: | Dcec/ Ccec/ Genuine Cummins |
| Type: | Self-Starting Diesel Generator |
| Installation Method: | Fixed |
| Stroke: | Six Stroke |
| Cooling Method: | Wind Cooling |
| Output Type: | AC Single Phase |
Genset's Data | |||
Genset Model | HQS300GF | ||
Prime Power | 300KW/375KVA | ||
Standby Power | 330KW/413KVA | ||
Rated Voltage | 400/230V (Adjustble) | ||
Frequency | 50Hz | ||
Radiator | 50°C suitable for tropical weather | ||
Charge Alternator | 24V | ||
Dimension(L*W*H) (mm) | 3150*1400*1800 (Open genset ) | ||
Dimension(L*W*H) (mm) | 4200*1600*2100 (Silent genset) | ||
Net Weight (kg) | 3300KG/4300KG with canopy | ||
Base Feul Tank Capacity | Enough for Genset 8-10 Hours Continuous Running | ||
Diesel Engine Data | |||
Brand | Cummins | ||
Model | QSM11-G2 | ||
Governor Type | Electrical | ||
Rotating Speed | 1500 rpm | ||
Engine Cooling Method | Water-cooled | ||
Cylinder Nos. | 6 | ||
Fuel consumption | 6L/h @75% full load | ||
Alternator Data | |||
Brand | Stamford / Leroy Somer/ China Stamford | ||
Model | HCI444E / LSA47.2VS1 / TPA314L6 | ||
Power Factor(COS Phi) | 0.8 | ||
Excite Type | Brushless SHUNT | ||
Connecting Type | 3 Phase & 4 Wires | ||
Insulation Degree | H | ||
Enclosure Degree | IP23 | ||
AVR voltage regulation rate | ≤±1% | ||
