| Price: | US $ 5120/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T,Western Union |
| Prod Model: | HQI-20GF |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Engine: | Isuzu |
| Alternator: | Stamford,Leroy Somer |
| MOQ: | 1 Set |
| QC System: | 4 Hours Factory Testing |
| Warranty: | 1 Year |
| Battery: | Maintenance-Free |
| Electrical System Voltage: | 24V |
| Type Of Injection: | Indirect Injection |
| Rated Current: | 33.5A |
| Stroke: | Four Stroke |
| Type: | Basic Diesel Generator |
| Cooling Method: | Water Cooling |
| Installation Method: | Fixed |
| Output Type: | AC Three Phase |
Model No. | HQI-20GF |
Prime Power(kw/kva) | 20KW/25KVA |
Standby Power(kw/kva) | 22KW/27.5KVA |
Rated Current(A) | 33.5A |
Rated Speed(rpm) | 1500RPM |
Rated Frequency(Hz) | 50HZ |
Rated Voltage(V) | 400V/230V(adjustible) |
Phase Number | 3 Phase |
Power Factor | 0.8 |
Voltage Regulation | AVR |
Genset Structure | Open,Silent,Trailer,Container,Automobile |
Weight(kg) appr | 680KG (open) |
Dimensions(L*W*H)mm appr. | 1500*700*1250mm (open) |
20kw/25kva Diesel Generator set with Isuzu Engine
Engine data
Engine Brand | ISUZU |
Engine Model | 4JB1-15 |
Fuel consumption(L/h) (full load) | 7.7 Litres/hour |
Cylinder Number | 4 CYLINDERS |
Bore * Stroke(mm*mm) | 93mm × 102mm |
Displacement(L) | 3 L |
Exhaust Temp(°C) | 500 °C |
Lub. Capacity(L) | 5.5L |
Coolant Capacity(L) | 4.5L |
Starting Voltage(V) | 12 |
Governor | Mechnical |
Base Fuel Tank | 8 hour |
20kw/25kva Diesel Generator set with Isuzu Engine
Alternator Details
Alternator Brand | Leroy-somer |
Alternator Model | LSA42.3VS2 |
Power Factor | 0.8 |
Connection Type | 3 phase 4 Wire |
Excitation Mode | Brushless |
Construction Type | SAE disc- coupling |
Steady state voltage regulation ratio | ≤±0.5% |
Insulation Class | H Class |
Protection Class | IP23 |
Auto Voltage Regulation | Yes |
Phone harmony wave factor THF | THF≤2% / TIF≤50 |
