| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Cooling Method: |
Wind Cooling |
| Stroke: |
Four Stroke |
| Installation Method: |
Portable |
| Type: |
Basic Diesel Generator |
Product Description
1. Small size and easy to move.
2. Popular in family use
3. Well-presented
4. Good quality and in low price
|
Model |
KH16000LTA3 |
|
Rated frequency(Hz) |
60 |
|
Rated output power(KVA) |
15 |
|
Maximum power(KVA) |
15.5 |
|
Rated voltage(V) |
220 |
|
Rated current(A) |
20.8 |
|
Rated Speed(rpm) |
3600 |
|
No. of Phase |
three phase |
|
Power factor(cos) |
0.8(lag) |
|
Insulation Grade |
F |
|
Pole Number |
2 |
|
Excitation Mode |
self-exciting and constant voltage (with AVR) |
|
Panel Type |
Digital Panel |
|
Overall dimension(L× W× H)(m) |
1040× 660× 740 |
|
weight(kg) |
248 |
|
Noise level(7m) dB(A) |
70 |
|
Structural Type |
Silent |
|
Engine Model |
R2V910 |
|
Engine Type |
V-twin, two-cylinder, four-stroke, DI |
|
Number of cylinders-Bore× stroke (mm) |
2-88× 75 |
|
Displacement (L) |
912 |
|
Compression ratio |
20: 01 |
|
Cooling Method |
Aircooled |
|
Lubrication Method |
Pressure splashed |
|
Starting Method |
Electrical |
|
Fuel Type |
0#(summer) -10#(winter)-2o#(chillness) diesel |
|
Lube capacity[L] |
1.7 |
|
Fuel consumption(g/kwh) |
300 |
|
Fuel tank capacity(L) |
21 |
|
Continuous Running time(hr) |
4 |
Our company is maunfacturer of diesel generator, the OEM of cummins engines with certify of CE, ISO9001.
Mainly produce and sale diesel gen-sets, inland diesel gen-sets from 3-3000kVA, marine energent diesel gen-sets from 12-500kw and kinds of imported diesel gen-sets, movable power station, low-noise, multi-PCS connection, remote monitoring, gen-sets with ATS, gas gen-sets etc.
With good quality and low price.
