FY-HAWT-20.0KW/200RPM(20KW Hortizontal Axis Wind is with high quality competitive prices and very mature design.
FY has advanced equipments(ABB TEST equipment for wind turbine generator) and manufacture process, completed quality management system(Samsung proven) and excellent technical team(Experts on Vertical Axis Wind Turbine/Generator/Blades/Electronic System) to provide high quality and environmental protection products and improved power supply solution and first-class after service for customers. We can supply long time warranty than other suppliers.
The wind generator are all made of NdFeB that We produces from 1996. The specific outer rotor magnetic circuit is designed in a way that the products have high generating efficiency, light weight, low starting torque, appealing appearance, easy installation and higher electric performance and use performance than the kindred products.
Horizontal Axis Wind Turbine(1-50KW) have special design; Controller/Inverter system is credible and professional, most of all, our WTG(Wind turbine generator) is quite special. (Directly drive, aslo We can supply wind turbine with gearbox)
Features & Main specification (FY-20KW Wind Generator Turbine)
Start with low wind speed, because we have a breeze to start patented technology, a little fan on the rotating wind power generation by natural factors
High wind energy utilization coefficient, normal wind turbine is 0.25, our wind Generator turbine can reach to 0.4
Gearless, direct drive, low RPM generator.
High standard, quality components for use in harsh and extreme environments for wind turbines.
High efficiency and Low mechanical resistance energy loss.
Excellent heat dissipation due to the Aluminium alloy outer frame and special internal structure.
High strength from the specially desy selecign structure and fully heat treatment Spray Aluminum
Generator is designed using speciallted material and treated to resist corrosion and oxidation.
Designed for reliable and long operational lifetime under long-term full output.
|
FY-20kw Wind Generator Turbine Technical parameters |
|
Wind rotor diameter (m) |
10 |
|
Blade material and quantity |
Fiber glass reinforced * 3 |
|
Rated power / max power (w) |
20k/30k |
|
Rated wind speed (m/s) |
10 |
|
Rated rotate speed (rpm) |
200 |
|
Working wind speed (m/s) |
3-30 |
|
Start up wind speed (m/s) |
3 |
|
Survived wind speed (m/s) |
45 |
|
Start torque(n/m) |
10 |
|
Working voltage (v) |
DC500v
AC380V |
|
Battery voltage / capcity (v, ah) |
12V200AH* 40Pcs |
|
Speed regulation method |
Yawing and hydraulic brake |
|
Stop method |
Manual brake |
|
Generator style |
Three phase, permanent magnet |
|
Wind turbine weight (kg) |
1400KG |
|
AAATower height / weight (m/kg) |
3350KG/18M |
|
Technologies FY-PMG-20KWA |
|
Electrical Specification |
|
Rated output power(KW) |
20KW |
|
Rated Rotation Speed(RPM) |
180 |
|
Recified DC current at Rated Output(A): |
48 |
|
Requied Torque at rated power(N/M) |
2135 |
|
Phase Resistance (Ohm): |
5.0 |
|
Output Wire Square Section(mm2) |
8 |
|
Output Wire Length(mm) |
200 |
|
Insultation: |
H Class |
|
Generator configuration |
3 phase star connected AC output |
|
Design Lifetime |
> 20 years |
|
Mechanical Specification |
|
Weight (KG) |
580 |
|
Starting Torque(NM): |
< 35 |
|
Rotor Inertia(Kg. m): |
3.75 |
|
Bearing Type: |
High standard Sweden SKF (Front) Sweden SKF (Rear) |
|
Material Specification |
|
Shaft |
High standard stainless steel |
|
Shaft Bearing |
High standard SKF or NSK bearing |
|
Outer Frame Material |
Cast iron, and appearance of High standard Aluminium alloy with TF/T6 heat treatment |
|
(TF/T6 full heat treatment for increasing the performance of aluminium alloy as follows. Heat 4-12 hours at 525-545 degrees Celsius, quench with hot water, and precipitation heat treatment for 8-12 hours at 155-175 degrees Celsius. ) |
|
Fasteners(nuts and bolts) |
High standard stainless steel |
|
Windings Temperature Rating |
180 degrees Celsius |
|
Magnet Material |
NdFeB (Neodymium Iron Boron) |
|
Magnets Temperature Rating |
150 degrees Ceisius |
|
Lamination Stack |
High specification cold-rolled steel |
Zhejiang Fengyuan Energy Technology Group Co., Ltd. is the professional manufacturer of small wind turbine generators which is a branch of Zhejiang Fengyuan Group Co., Ltd, The company has an established product range, and undertakes active investment in the development and promotion of both proven and innovative renewable energy technologies. Specializes in research, development, manufacturing, service as one large-scale and all-around "nomarchy high technology corporation. We have solar PV, scale-middle wind turbines, LED lighting and have got CE, ISO 9001, TUV and other product certificate, we have Zhejiang Wenzhou, Jiaxing Haining and Shangdong Linshu three manufacturer sites, after these three manufacturer sites finished building the annual value of production can reach to 50 hundred million RMB.
After 10 years development the products of wind turbine generator range from 400W, 1KW, 2KW, 3KW, 5KW, 10KW to 50KW with CE certificates honored. Thanks to the wide sorts and good quality, the products have already taken up the majority of domestic market and have been exported to more than 40 countries, say, Britain, France, the United States, Canada, New Zealand, Argentina, India etc, received high affection and reputation from the users.
Zhejiang Fengyuan Group Headquarters in Jiaxing Haining, for our Group have nearly a subsidiary of 18 to Join, have a branch like Zhejiang Fengyuan Energy Technology Co., Ltd, Shandong Tuoyuan Energy Technology Co., Ltd and so on, with a total registered capital of up to 500 million RMB. For our Shandong Tuoyuan Energy Industrial Park have finished, which is a subsidiary of Zhejiang Fengyuan Energy Technology.
Zhejiang Fengyuan Energy Technology will devote to the continuous development of green power resources and build the wonderful green world, and will try it's best supply excellent service!
