TOPS gasoline generator:
Gasoline generator sets adopt different diesel engines and brushless generators. Generally adopt 4-stroke OHV engine( 950 series adopts 2 stroke engine), low fuel consumption, high reliability; It is easy to maintain as adopting brushless a.c. generator and CDI ignition system.If fitted with large capacity of fuel tank, can run for 12hours;Also charge for battery with 12V DC.The types of generator sets are quick-starting, stable-running, little vibration, low noise, light weight, small volume, compact structure, suitable for areas on mining, factory, working on field, engaging in construction and army as movable power or electric power in ship, also suitable for areas on animal husbandry, fishery, forest, orchard, guesthouse and business as standby power.
Advantage:
Portable gas generator
1 one year warranty
2 home standby use
3 Efficient fuel consumption
4 Overload circuit breaker
Model |
LTP2500 |
LTP 3500 |
LTP 4500 |
LTP 6500 |
LTP 7500 |
Frequency(Hz) |
50/60 |
Rated AC output(KW) |
2.0 |
2.5 |
3.0 |
5.0 |
6.0 |
Max. AC output(KW) |
2.2 |
2.7 |
3.2 |
5.5 |
6.5 |
AC voltage |
110,120,220,230 |
DC Output (V/A) |
12/8.3 |
Engine model |
LTP 168 |
LTP 168-2 |
LTP 170 |
LTP 188 |
LTP 190 |
Engine type |
4-stroke; air-cooled,gasoline |
Max. Output (hp/rpm) |
5.5/3600 |
6.5/3600 |
7.0/3600 |
13.0/3600 |
15.0/3600 |
Displacement Capacity(cc) |
163 |
196 |
208 |
389 |
420 |
Fuel tank capacity (L) |
15 |
15 |
15 |
25 |
25 |
Continuous work (h) |
12.5 |
10.5 |
10.5 |
9 |
8.6 |
Fuel type |
90#Petrol |
Spark Plug |
F6TC |
F6TC |
F6TC |
F6RE |
F6RE |
Starting system) |
Recoil/Electric |
Noise Level at 7m(dB) |
65 |
65 |
69 |
71 |
72 |
Gross Weight(kg) |
42 |
48 |
49 |
95 |
98 |
Dimension(mm) |
615x430x500 |
550x440x480 |
605x470x465 |
690*545*570 |
780*545*570 |
20ft Container QTY |
240 |
212 |
192 |
136 |
120 |
40HQ Container QTY |
470 |
550 |
495 |
288 |
252 |
