ST Single-phase and STC Three-phase AC Alternator

ST Single-phase and STC Three-phase AC Alternator
Price: US $ 100-330/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 5/Piece
Pay Type: L/C,T/T,D/P,Paypal,Money Gram

ST low speed alternator price

ST Series Single Phase A. C. Aynchronous Generator / Alternator

The ST series generators are mainly designed to serve as power generating unit of small capacity, which supply electricity for lighting purpose in ships, for house-hold electric devices used in towns or villages.
The construction of the generators is of drip-proof, salient pole rotating field self excitation and constant voltage type. The alternator interior is used with high quality electric magnetic and Electric materials. Stator insulation is class B. These generators are elegant in appearance, tight in construction and easy maintenance. IEC standard are adopted on dimension, these dimension are suitable for using in Australia, Europe, America and other countries with the end covers to be model B.
The alternators are of harmonic wave self-exciation constant voltage system and automatic voltage control excitation constant voltage system,

Both of them have Excellent dynamic performance, convenient and reliable in operation. These generators are excellent in appearance and easy to maintain. Dimensions are adopted according to i. e. C Standards.
The voltage of the alternator is 230V of 115V, the frequency is 50Hz. Its operation mode is of continuous duty. It can provide 60Hz and the other voltage's generator according to necessary.
The other voltage's generator according to necessary.
The alternator can be coupled with a prime mover directly or through a V-belt, with 5% change of speed of the prime mover under load Variation of 0~100%, at a voltage of 230V or 115V, 50Hz or 60Hz to get a satisfactory constant voltage performance.

Operating Condiyions:
1. Altitude: Not exceed 1000m.
2. Cooling air temperature: 258~313K 3. Relative air humidity: Not exceed 90%.

Note:
For details or other requirements, please feel free to contact us.
ST    Series  Single  Phase  A. C.   Synchronous  Generator  /  Alternator
Model Output  (KW)Current  (A)Voltage  (V)Power   factor Pole  number Speed   r. p. mN, W  (kg)G. W  (kg)Packing  sizeIn  a  20'     containerFrequency(Hz)
Series  connection Parallel  connectionSeries  connection Parallel  connection50/60
ST-228.717.4230V115V141500/180043.54652*29.5*46425
ST-33132648.55152*29.5*46425
ST-5521.743.5788562*35*53236
ST-7.57.532.665.28810762*35*53236
ST-101043.587104.611768*42*58168
ST-121252.2104.411712868*42*58168
ST-151565.2130.414516073*45*64120
ST-20208717416718073*45*64120
ST-2424104208187200


ModelOuput
(kw)
Rated Capacity
(KVA)
Rated Current
(A)
Pole numberRated Speed
r. p. m
STC-333.85.441500
STC-556.39
STC-7.57.59.413.5
STC-101012.518.1
STC-12121521.7
STC-151518.827.1
STC-20202536.1
STC-303037.554.1
STC-40405072.2
STC-505062.590.2
STC-646480115.5
STC-757593.8135.3


Prod Model: ST series
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Model: St Series Alternator
Output: 2kw-24kw
Certificate: CE / ISO9001
Duty: Continuous(S1)
Rated Voltage: 230V, 220V, 240V
Winding: 100% Copper Wire
Phase: Single Phase
Frequency: 50Hz or 60Hz
Warranty: 1 Year
Color: as Request
