Soundproof /Silent Diesel Generator with Shangchai Engine

Soundproof /Silent Diesel Generator With Shangchai Engine

1.OEM, Factory Price
2.ISO9001, CE, SGS Certificate
3.Quality first, Service first
Shangchai series diesel generator adopts the famous China-made engine Shangchai diesel engine and the world famous generator stamford.It has the advantage of low oil consumption, high reliability, high performance, low price etc has win a good reputation in the China market and overseas and price is more competitive and attracting!

The components of the genset:
(1) Shangchai Diesel Engine;(2) Stamford Alternator;(3) Control Panel

Technical parameters of diesel generator sets:
Generator Set:
Generator Model:GFSD-XZ250
Prime Power(KW):250KW
Rated Voltage(V):400/220V
Frequency(Hz):50Hz
Power Factor:0.8(lagging)
Rated Current (A):360/396A
Dimension (L×W×H) (mm):2980*1150*1680(L*W*H mm)
Genset weight (KG):3300KG

Diesel Engine:
Brand:Shangchai
Type:G128ZLD2
Power(KW):250KW
Number of Cylinders:6
Rotating Speed:1500RPM
Aspiration:Turbocharged after water-cooled
Bore×Stroke(mm):135*150mm
Displacement(L):8L
Compression Ratio:17.0:1
Speed Governor:Electrical
Cooling System:Water-cooled
Fuel Consumption at 100% Load:≤210g/kwh
Starting Method:24V Electrical starting

Alternator:
Brand:Stamford Brushless
Rated Voltage(V):120V-690V
Rated Volumn(kVA):312.5kVA
Rated Power(KW):250KW
Connecting Type:3 Phase and 4 Wires
Frequency:50/ 60Hz 1500RPM/1800RPM
Number of Bearing:Single/Double
Protection Grade:IP23/IP44
Altitude:Within the limits of 1000m, temperature of 40ºC or OEM
Exciter Type:Brushless, Self-exciting, AVR automatic voltage regulating
Insulation Class:H/F
Telephone Influence Factor (TIF):50
THF:<2%
Voltage Regulation, Steady State:≤±0.5%
Transient State Voltage:≤-15%~+20%

Test before shippment
1, Each Generator Set shall be put into commission more than 4 hours totally, tested on idleload, fully load and 10% overload.
2, Noise level shall be tested.
3, All of the meters on the control panel shall be tested.
4, The appearance of the Set and the label, nameplate shall be tested."
Voltage available:50Hz:380-400-415V/ 220-230-240V;60Hz:220-380-416-440-480V/ 110-208-220-240V.Any special voltage is also available as cilent's request.

Packing & Warranty
Packing:Plywood or Metal Case.
Delivery Time:Less than 25 working days after receiving prepayment.

Warranty:One year or 1, 000 hours from the date of shippment
Our warranty standard is higher than most manufacturers for about 25%, because we are confident in our strict test and quality management during each step of manufacture.

Control System:

Basic control system, the basic type control system is provided with a current meter, a volmeter, a frequency meter, an oil pressure guage, a water thermometer and indicator lights on the control cabinet and 4 additional protection fuctions are to be provided as required by customers.

Optional AST & ATS Control System:

AST (Automatic Start Type Control System), Optional Automatic Start Type System is provided with a 101A control module or a DACT704 module with LCD display.When there is an interruption in the commercial power supply (or there is a start signal in other generator sets), this generator set will, subject to time delay acknowledgement (0-30 S adjustable), be automatically started (1-8 times adjustable).In addition, it is provided with a basic protection function and digital or meter indication of voltage, current, frequency and rotation speed parameters.

ATS (Automatic Transfer System), The optional system is provided with a fully automatic transfer switch, a control electric apparatus and an indicator light on the control panel and is coordinated with an automatic type contral cabinet, thus serving the fuction of automatic changeover between the power supplied by the grid and the power generated by the genset.
