Feature
Canopied models for noise reduce performance
Double base frame for reducing vibrations
Larger fuel tank for longer autonomy
Integrated wheel on canopies
V-Twin diesel engine in models DG12000SE/SE-3
Control panel
Overload protection through intensity control LED display.
Leakage breaker 30mA for machine and person protection.
Pre heating system for easier starting in cold conditions.
LED digital display 4 functions.
Emergency STOP button.
DC 12V output 8, 3A.
Earth connection.
ATS automatic start in Electric start models with optional Remote Control and Trimmer.
Engine
Diesel 4 stroke Direct injection Air cooled.
Low oil alarm protection with automatic shuf off engine.
V Twin cylinder engine in DHY12000LE/LE-3 models.
Direct electronic injection system.
Alternator
100% Copper Winding.
AVR automatic voltage regulation.
Brush type alternator.
Diesel Generator Set
|
Rated PowerkW/kVA
|
5 |
|
Max.PowerkW/kVA |
5.5 |
|
Frequency (Hz) |
50HZ |
|
Voltage (V) |
230 |
|
Current (A) |
22 |
|
Sockets |
EU 2x16A |
|
Display |
LED or LCD |
|
Battery (Ah) |
No |
|
Fuel Tank Capacity (L) |
15 |
|
Running Time under 50% Load (hr.) |
6.3 |
|
Noise Level behind 7 Meters (dBA) |
65 |
|
DC Output (V/A) |
12 / 8.3 |
|
ATS Port as optional |
choose |
|
Air Pre-heater as optional |
Yes |
|
Remote Control as optional |
Yes |
|
Push Wheels kit as optional |
Yes |
|
Engine |
Engine |
D400E |
|
Power Output (HP/3000rpm) |
10 |
|
Start Method |
Electric Start |
|
Displacement (cc) |
406 |
|
Oil Capacity (L) |
1.65 |
|
Alternator |
Alternator |
5kw190L-140 |
|
Rated Power (kW) |
5 |
|
Power Factor (Cosφ) |
1 |
|
Voltage Regulation |
AVR / Brush |
|
Transportation Data |
N.G.kg |
152 |
|
G.W.kg |
164 |
|
Product Dimension (mm) |
920*525*760 |
|
Package Dimension (mm) |
960*570*790 |
|
Max Quantity(set)/Container |
48/20GP;96/40GP;144HQ |
