Model: FD3.2-2KW FD3.8-2KW
Rotor Diameter: 3.2m or 3.8m
Number of Blades: 3PCS
Material of Blades: Fibre glass expoxy
Cut-in wind speed: 3m/s
Working wind speed: 3-25m/s
Survival wind speed: 50m/s
Rated wind speed: 12m/s (FD3.8 rated wind speed is 10m/s)
Rated rotation speed: 300r/min (FD3.8 rated rotation speed is 280rpm)
Rated output power: 2kw
Max output power: 3kw
Type of tower: Guy wire tower or tilting up tower
Type of generator: Permanent-magnet 3 Phase AC
Speed regulation method: Yaw
Working voltage: DC48V/DC120V/DC300V or special request
Operating Temperature: -40---+60
Tower height: 7m, 12m, 15m or special request
Wind turbine main body weight: 120kg
Life span: more than 15 years
Warranty: 2 years
Working system: We can provide whole off-grid working system; On-grid working system. You can take the whole system from us, also you can take any parts of the system from us.
For more details about wind turbine, pls contract with us!
Qingdao Henryd Wind power Equipment Co., Ltd. is specialized small wind turbine generator manufacture in China. We own over 10 years practical experience in technical research, development and application of wind turbines. Also we have a strong r & d team to give our wind turbine tech supports. Our sales dept with many years experience in trading area will give you more supports.
We provide:
1)300w-30kw horizontal wind generator off-grid working system
1kw, 2kw,2.5kw 3kw, 5kw, 10kw, 20kw 25kw 30kw on-grid working system
2.)Vertical axis wind turbine 1kw 2kw,3kw 5kw
5-7 pcs stallout FRB blades.
3.) Variable pitch wind turbine 2kw 3kw 5kw 10kw 20kw 30kw 50kw 60kw
4.)2.2m-24m(diameter) frb, horizontal axis, 3 PCS aerofoil blades, past wind tunnel test, high efficiency.
5. )guy wire tower, independance tower, tilting up tower, hydraulic tower
--factory direct sales--
Good price and higher quality, provide technical support more professional.
