D-2.8m, D-3.2m blades rotor for different wind place;
Wind turbine with tail system, auto yaw;
Wind turbine with speed regulated system, can work in rich wind speed place.
Lower cost than pitch controlled wind turbine; Same safety and reliable.
FD3.2-1.5kw wind turbine normal data:
Model: | FD3.2-1500W |
| Rotor Diameter: | 3.2m |
| Number of Blades: | 3pcs |
| Material of Blades: | Fibre glass expoxy |
| Cut-in wind speed: | 3m/s |
| Working wind speed: | 3-25m/s |
| Survival wind speed: | 40m/s |
| Rated wind speed: | 10m/s |
| Rated rotate speed: | 380rpm |
| Rated output power: | 1500w |
| Max output power: | 2300w |
| Type of tower: | Guy wire tower |
| Type of generator: | Permanent-magnet 3 phrase AC |
| Speed regulation method: | Yaw |
| Working voltage: | DC24V,DC48V optional |
| Operating Temperature: | -60ºC---+60ºC |
| Tower height: | 6m,8m,9m,12m |
| Tower weight: | 65kg |
| Wind turbine main body weight: | 75kg |
| Measurement(CBM): | 1.5 |
| Life span: | WT 20 years; |
| Warranty: | 2 years after installation |
Qingdao Henryd Wind power Equipment Co., Ltd. is specialized small wind turbine generator manufacture in China. We own over 10 years practical experience in technical research, development and application of wind turbines. Also we have a strong r & d team to give our wind turbine tech supports. Our sales dept with many years experience in trading area will give you more supports.
We provide:
1)300w-30kw horizontal wind generator off-grid working system
1kw, 2kw,2.5kw 3kw, 5kw, 10kw, 20kw 25kw 30kw on-grid working system
2.)Vertical axis wind turbine 1kw 2kw,3kw 5kw
5-7 pcs stallout FRB blades.
3.) Variable pitch wind turbine 2kw 3kw 5kw 10kw 20kw 30kw 50kw 60kw
4.)2.2m-24m(diameter) frb, horizontal axis, 3 PCS aerofoil blades, past wind tunnel test, high efficiency.
5. )guy wire tower, independance tower, tilting up tower, hydraulic tower
--factory direct sales--
Good price and higher quality, provide technical support more professional.
