3kw Variable pitch wind turbine
on/off grid working system
Wind solar hybrid system
on grid working system work together with SMA or Aurora inverter
Whole off grid working system
reliable and safety wind turbine, high efficiency generator
corrosion preventing treatment
Used for the sea side, island, river side, home, vlla, garden...
Huaya pitch controlled wind turbine 3kw technical data:
| Blades rotor Diameter (m) | 4 |
| Material and number of the blades | FRB 3 PCS |
| Rated power / max power (w) | 3k/4k |
| Rated wind speed (m/s) | 9 |
| Startup wind speed (m/s) | 3 |
| Working wind speed (m/s) | 3-25 |
| Survived wind speed (m/s) | 40 |
| Rated rotation speed (r/min) | 300 |
| Working Voltage (V) | DC24--300v |
| Generator style | 3 phase ,AC PMG |
| Speed regulation method | Pitch controlled + yaw |
| Stop method | Brake by hand drag + electromagnet brake |
| Working system | Off-grid working system/on grid working system |
| Guy wire tower Height | 8m,9m,10m,12m,15m |
| Tilting up Tower height | 8m,9m,10m,12m,15m |
| Wind turbine main body weight(kgs) | 140 |
Huaya pitch controlled wind turbine features
Blades rotor: Blades rotor efficiency can reach 0.42. Noise level is less than 65db, and balance adjustment has been carried out strictly before leaving factory.
Generator: Blades rotor drives directly. Lower rotation speed, PMG synchronous generator, over load capacity is 150%.
Pitch controlled wind turbine: Adopt stable pitch controlled system, can be used in variable environments
Low failure rate
Speed regulates Performance: The precision of pitch controlled system is 10 r/min, and never over speed at gale.
Low Start-up Wind Speed: According to different wind conditions, adjust the blade initial angle to make wind turbine start up at low wind speed.
The start-up wind speed is ≤3m/s.
Manual brake: Reliable braking system, easy to operate, can stop wind turbine at any time.
Automatically undo cable: slip rings undo the cable automatically. Ensure the cable has not twist. Double carbon brushes structure make sure power transfer without failure.
Well-adapted Wind turbine: The operation wind speed is 3-30m/s.
For more technial data, plscontact with us via mail.
Qingdao Henryd Wind power Equipment Co., Ltd. is specialized small wind turbine generator manufacture in China. We own over 10 years practical experience in technical research, development and application of wind turbines. Also we have a strong r & d team to give our wind turbine tech supports. Our sales dept with many years experience in trading area will give you more supports.
We provide:
1)300w-30kw horizontal wind generator off-grid working system
1kw, 2kw,2.5kw 3kw, 5kw, 10kw, 20kw 25kw 30kw on-grid working system
2.)Vertical axis wind turbine 1kw 2kw,3kw 5kw
5-7 pcs stallout FRB blades.
3.) Variable pitch wind turbine 2kw 3kw 5kw 10kw 20kw 30kw 50kw 60kw
4.)2.2m-24m(diameter) frb, horizontal axis, 3 PCS aerofoil blades, past wind tunnel test, high efficiency.
5. )guy wire tower, independance tower, tilting up tower, hydraulic tower
--factory direct sales--
Good price and higher quality, provide technical support more professional.
