Model
KGE7500
Rated frequency (Hz)
50
60
Rated voltage (V)
220; 230; 115/230
110; 120; 110/220; 120/240
Rated output power (kW)
6.0
6.5
Max output power (kW)
6.5
7.0
Rated rotation speed (rpm)
3000
3600
DC output:
12V 8.3A
Phase number
Single phase
Noise level dB (A)/7m (zero load-full load)
72-74
Fuel tank capacity
25L
Fuel consumption
3.1L/hr
Continuous operating hour
8hr
Engine Type
4-stroke single-cylinder air-cooled, OHV
Engine Model
KG420
Displacement
420ml
Max. Power output
16HP
Ignition system
Non-contact transistorized magneto
Starting system
Recoil or Electric start
Lube oil brand:
SAE10W30 (above CC grade)
Oil capacity
1.1L
Dimension(L*W*H mm)
680*500*540
N. W/G. W (Kg)
88kg/90kg
Carton dimension(L*W*H mm)
700*520*570
QTY 20FT/40FT
132/276
Model |
KGE7500 |
|
Rated frequency (Hz) |
50 |
60 |
|
Rated voltage (V) |
220; 230; 115/230 |
110; 120; 110/220; 120/240 |
|
Rated output power (kW) |
6.0 |
6.5 |
|
Max output power (kW) |
6.5 |
7.0 |
|
Rated rotation speed (rpm) |
3000 |
3600 |
|
DC output: |
12V 8.3A |
|
Phase number |
Single phase |
|
Noise level dB (A)/7m (zero load-full load) |
72-74 |
Fuel tank capacity |
25L |
Fuel consumption |
3.1L/hr |
Continuous operating hour |
8hr |
Engine Type |
4-stroke single-cylinder air-cooled, OHV |
Engine Model |
KG420 |
Displacement |
420ml |
Max. power output |
16HP |
Ignition system |
Non-contact transistorized magneto |
Starting system |
Recoil or Electric start |
|
Lube oil brand: |
SAE10W30 (above CC grade) |
|
Oil capacity |
1.1L |
Dimension(L*W*H mm) |
680*500*540 |
N. W/G. W (Kg) |
88kg/90kg |
Carton dimension(L*W*H mm) |
700*520*570 |
QTY 20FT/40FT |
132/276 |
National Machinery Group Co., Ltd. It is a professional supplier of Air-Cooled Diesel Engine (Model: KM170F, KM178F, KM186F, KM186FA, KM188F-A, KM188F-B), Water-Cooled Diesel Engine (Model: ZS195, ZS1100, ZS1105, ZS1110, ZS1115, ZS1125, ZS1130), Portable Generator (KDE2500E, KDE3500E, KDE6500E, KDE3700T, KDE6700T, KDE6700TA), Industrial Generator Set (Powered by Cummins, Perkins, Deutz, Yanmar, Kubota, Lovol, Weichai, Ricardo, Shangchai, Wudong, Quanchai etc), Power Tiller(Model: KDT-105, KDT-135), Welding Generator, Water pump set (Model: KDP20, KDP30, KDP40, KDP80T) etc, with 10 yers of experience in research, development and selling, we can supply you products with good quality and reasonable price.
