Model
KGE4500
Rated frequency (Hz)
50
60
Rated voltage (V)
220; 230; 115/230
110; 120; 110/220; 120/240
Rated output power (kW)
3.0
3.3
Max output power (kW)
3.3
4.5
Rated rotation speed (rpm)
3000
3600
DC output:
12V 8.3A
Phase number
Single phase
Noise level dB (A)/7m (zero load-full load)
69-72
Fuel tank capacity
25L
Fuel consumption
2.45L/hr
Continuous operating hour
10hr
Engine Type
4-stroke single-cylinder air-cooled, OHV
Engine Model
KG270
Displacement
270ml
Max. Power output
9HP
Ignition system
Non-contact transistorized magneto
Starting system
Recoil or Electric start
Lube oil brand:
SAE10W30 (above CC grade)
Oil capacity
1.1L
Dimension(L*W*H mm)
680*500*540
N. W/G. W (Kg)
73kg/75kg
Carton dimension(L*W*H mm)
700*520*570
QTY 20FT/40FT
132/276
Model |
KGE4500 |
|
Rated frequency (Hz) |
50 |
60 |
|
Rated voltage (V) |
220; 230; 115/230 |
110; 120; 110/220; 120/240 |
|
Rated output power (kW) |
3.0 |
3.3 |
|
Max output power (kW) |
3.3 |
4.5 |
|
Rated rotation speed (rpm) |
3000 |
3600 |
|
DC output: |
12V 8.3A |
|
Phase number |
Single phase |
|
Noise level dB (A)/7m (zero load-full load) |
69-72 |
Fuel tank capacity |
25L |
Fuel consumption |
2.45L/hr |
Continuous operating hour |
10hr |
Engine Type |
4-stroke single-cylinder air-cooled, OHV |
Engine Model |
KG270 |
Displacement |
270ml |
Max. power output |
9HP |
Ignition system |
Non-contact transistorized magneto |
Starting system |
Recoil or Electric start |
|
Lube oil brand: |
SAE10W30 (above CC grade) |
|
Oil capacity |
1.1L |
Dimension(L*W*H mm) |
680*500*540 |
N. W/G. W (Kg) |
73kg/75kg |
Carton dimension(L*W*H mm) |
700*520*570 |
QTY 20FT/40FT |
132/276 |
