Model
KGE3500
Rated frequency (Hz)
50
60
Rated voltage (V)
220; 230; 115/230
110; 120; 110/220; 120/240
Rated output power (kW)
2.5
2.8
Max output power (kW)
2.8
3.5
Rated rotation speed (rpm)
3000
3600
DC output:
12V 8.3A
Phase number
Single phase
Noise level dB (A)/7m (zero load-full load)
65-69
Fuel tank capacity
15L
Fuel consumption
1.13L/hr
Continuous operating hour
13hr
Engine Type
4-stroke single-cylinder air-cooled, OHV
Engine Model
KG200
Displacement
196ml
Max. Power output
6.5HP
Ignition system
Non-contact transistorized magneto
Starting system
Recoil or Electric start
Lube oil brand:
SAE10W30 (above CC grade)
Oil capacity
0.6L
Dimension(L*W*H mm)
590*425*435
N. W/G. W (Kg)
46kg/48kg
Carton dimension(L*W*H mm)
605*435*450
QTY 20FT/40FT
235
Model |
KGE3500 |
Rated frequency (Hz) |
50 |
60 |
Rated voltage (V) |
220; 230; 115/230 |
110; 120; 110/220; 120/240 |
Rated output power (kW) |
2.5 |
2.8 |
Max output power (kW) |
2.8 |
3.5 |
Rated rotation speed (rpm) |
3000 |
3600 |
DC output: |
12V 8.3A |
Phase number |
Single phase |
Noise level dB (A)/7m (zero load-full load) |
65-69 |
Fuel tank capacity |
15L |
Fuel consumption |
1.13L/hr |
Continuous operating hour |
13hr |
Engine Type |
4-stroke single-cylinder air-cooled, OHV |
Engine Model |
KG200 |
Displacement |
196ml |
Max. power output |
6.5HP |
Ignition system |
Non-contact transistorized magneto |
Starting system |
Recoil or Electric start |
Lube oil brand: |
SAE10W30 (above CC grade) |
Oil capacity |
0.6L |
Dimension(L*W*H mm) |
590*425*435 |
N. W/G. W (Kg) |
46kg/48kg |
Carton dimension(L*W*H mm) |
605*435*450 |
QTY 20FT/40FT |
235 |
National Machinery Group Co., Ltd. It is a professional supplier of Air-Cooled Diesel Engine (Model: KM170F, KM178F, KM186F, KM186FA, KM188F-A, KM188F-B), Water-Cooled Diesel Engine (Model: ZS195, ZS1100, ZS1105, ZS1110, ZS1115, ZS1125, ZS1130), Portable Generator (KDE2500E, KDE3500E, KDE6500E, KDE3700T, KDE6700T, KDE6700TA), Industrial Generator Set (Powered by Cummins, Perkins, Deutz, Yanmar, Kubota, Lovol, Weichai, Ricardo, Shangchai, Wudong, Quanchai etc), Power Tiller(Model: KDT-105, KDT-135), Welding Generator, Water pump set (Model: KDP20, KDP30, KDP40, KDP80T) etc, with 10 yers of experience in research, development and selling, we can supply you products with good quality and reasonable price.
