| Price: | US $ 62990/Set |
|---|---|
| Trade Terms: | FOB,EXW,CIF |
| Min Order: | 1/Set |
| Pay Type: | L/C,T/T,Western Union |
Core Features:
Manufacturer supply
Capacity: 1.0-1.7kg raw material generate 1kw/h power
Max power supply range:10-600kw
Continuous power supply range: 8-480kw
Standard componient and assembly
Multi-option of control panel
With CE and ISO certificate
(Single set power supply range: 10 - 600 kw, ≥2 sets parallel together to form large power, Eg. 500kw*3 sets = 1500KW)
| Model Number (Engine Type) | LHNG300 |
| Brand Name | LVHUAN |
| Prime Power/Standby Power | 240KW/300KW |
| Rated Speed | 1000/1200RPM |
| Rated Frequency | 50/60Hz |
| Rated Voltage | 400V/230V |
| Phase | AC 3-Phase, 4 wire |
| Voltage Stability | ≤±2% |
| Voltage transient | ≤±10% |
| Voltage Stable time | ≤1s |
| Heat consumption | ≤11mj/kw.h |
| Lubricant consumption | ≤1.0g/kw.h |
| Engine Capacity | 32 L |
| Cylinder Number | 6 |
| Cylinder Bore | 190mm |
| Stroke | 210mm |
| Starting System | DC 24V electric motor |
| Cooling method | water cooler |
| Lubricant method | Passive and flying lubricant |
| Isolation class | H |
| Protection | IP23 |
| Alternator | Siemens |
| Power Factor | 0.8 lagging |
| Exciting method | brushless |
| Colour | your choice |
| Certificates | ISO 9001:2008, CE |
| Warranty | 1 year or 1000 running hours arrives first |
| Type | Open |
| Control system | Automatic alarm system |
| Size | 5300x1970x2170mm |
| Weight | 8200kg |
Biomass generator working principle:
1. Condition: Change biomass into biomass gas by biomass gasifier
2. Gas mix with air outside of engine's cylinders
3.Mixed gas into cylinder and explode inside of cylinders to change gas energy into power force
4.Power force drive alternator to generator electric power
5.Water circules form water tank to engine to bring the engine heat
6. Optional device of CHP, silent canopy and mobilable trailer.
7. Control panel system control all operation
Machine supply details:
Ignition system:We adopt ignition system of magneto which produced by American ALTRONIC company,including:magneto,high-tension coil,sparking plug.
Starting system: DC24V electric motor,12v190 adopt ST710 of direct-current.
Pressure charging system:Pulse Mixed-flow supercharger, compression ration is 1:8,meet engine's requirement for gas-flow rate.
Speed regulating system: EGS gas controller of American WOODWARD Company.
Full automatic system for optional: ATS for automatic switch form national grid power to generated power, double direction.
Low voltage cables between generator set and control room: available if needed.
We have a sales staff can speak in Russian, If you from Russia, Kazakhstan , Ukraine, Belarus, Uzbekistan, and other countries,you can visit our Russian website: www.lvhuanpower.ru.
| Prod Model: | LHBMG300 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Prime Power/Standby Power: | 240kw/300kw |
| Rated Speed: | 1000/1200rpm |
| Rated Frequency: | 50/60Hz |
| Rated Voltage: | 400V/230V |
| Power: | 300kw |
