Rated Speed | 1500RPM/1800RPM |
Rated Frequency | 50/60Hz |
Rated Voltage | 220/380V,230/400V,110/220V,240/416V, 254/440, 277/480V |
Phase | AC 3-Phase, 4 wire |
Voltage Stability | ≤±2% |
Voltage transient | ≤±10% |
Voltage Stable time | ≤1s |
Heat consumption | ≤11mj/kw.h |
Lubricant consumption | ≤1.0g/kw.h |
cliyder namer | 12 or 6 |
Starting System | DC 24V electric motor |
Cooling method | water cooler |
Lubricant method | Passive and flying lubricant |
Isolation class | H |
Protection | IP23 |
Alternator | Chinese Stamford |
Power Factor | 0.8 lagging |
Exciting method | brushless |
Colour | your choice |
Certificates | ISO 9001:2008, CE |
Warranty | 1 year or 1000 running hours which arrives first |
Type | Open |
Control system | Automatic alarm system |
overhual time | more than 3000hours |
intake mode | natural intake |
sparking mode | sparking pl |
noise | less than 105dB(A) |
exhaust temperature | less than 650C
Conditions for Using 1. The temperature of the gas should not surpass 40°C when the distance between the gas and the pressure regulating valve for air inflow is 1m. 2. The range of the pressure that this natural gas generator set can sustain should be 3kpa-10kpa and the fluctuated frequency should not surpass 1kpa/min. 3. The content of the methane in the natural gas should not be lower than 45% and its fluctuated frequency should not surpass 2%/min. 4. The content of H2S should not surpass 200mg/Nm³. 5. The granularity of the impurity should not surpass 5µm and the content of the impurity should not surpass 30mg/Nm³. 6. The content of water in biogas used in this natural gas generator set should not surpass 40g/Nm³. 7. For natural gas with methane of about 70%-90%, low density natural gas generator should be used. For those gases which cannot reach the conditions above, this biogas generator set should be specially allocated after evaluation according to the specified composition, pressure, temperature, etc, provided. |
Service commitment:
1.pre-sale service:
We will send our engineer to prospect the site of power station free to charge.According to the situation of site we can supply you many drawings which can meet the requirement of design and construction,like power station floor plan,engineering flow sheet of circle cooling system,genset installation,genset foundation,electrical connection and some other techincal support etc.
2.Sale service:
we will send our engineer to the site to guide you the installation of generator set, subsystem and relative equipment.We will debug the generator set till it can generate power successfully.We will also supply a technical training to the operators.You also can send your staff to our company.We can train you till you can operate the generator set and during this time we can offer you board and lodging free of Charge.
3.After-sale service:
(1)in our company, different people is in charge of different area,we will response periodically and support you technical service free of charge,include equipment debugging,fault eliminating,technical advice,maintenance assistant,etc.
(2)For the quality problem, we will service for you free of charge during the guarantee period.
(3)One year guarantee period and lifetime service.
(4)Insisting on principle of "solving problems first,trying to recover the generator set as soon as possible and then analysis the reason",we solve quality problem in time when genset doesn't work,We insure to help our clients to gain the biggest economic profit.
We aslo supply spare part service:
1.Application scope of the Accessories,such as 12v190,8v190,6190,6135 and other engine types
2.All parts were from original factories or professional factories,complete in specification,keep good quality
Shandong Chaiwei power Co., Ltd, which is a leading manufacture of diesel generator and gas generator in China, our generator from 20kw to 1000kw with CE ISO SONCAP certificate & OEM available, which have exported to Middle East, South America, Russia, Africa, and got a high reputation on the overseas market.
About the products, we have self-developed team to design and improve the generator sets to meet different customers` need. We have completed quality inspection system to make sure each product that customer get is perfect; We have professional after-sale team to guarantee your generator set be correctly installed and running normally. CHARGEWE will bring best products and service with most reasonable price for you. From the foundation of our company, we committed to leading as pioneer of the generator industry and contributing ourselves for China's electricity industry. We believe CHARGEWE will be your best partner in generator area.
Any comments or questions, feel free to tell me. You will surely find our sincerity and value in both our products and service.
