3kw Diesel Generator (KDE3500E)
Price: |
US $ 450/Piece |
Trade Terms: |
FOB |
Min Order: |
132/Piece |
Pay Type: |
L/C,Western Union |
1. New automatic voltage regulator(AVR) ensures the diesel generator steady voltage output
2. Low oil pressure alarm system, which can shut down the engine automatically.
3. Electric start system ensures rapid start of the set.
4. 3-phase output meets the diversified demands from customer.
Model |
KDE3500E |
Frequency (HZ) |
50 |
60 |
Rated Output (KVA) |
2.8 |
3.0 |
Maximum Output (KVA) |
3.0 |
3.2 |
Rated Voltage (V) |
115/230 |
120/240 |
Rated current (A) |
24.4/12.2 |
25/12.5 |
Rated rotation speed (rpm) |
3000 |
3600 |
Phase No. |
Single phase |
Power Factor |
1.0 |
Excitation Mode |
Self-excitation, 2 pole and constant voltage (AVR) |
DC Output |
12V. /8.3A , Terminal Post |
Noise Level (7m) dB(A) |
72 |
Engine Model |
KM178FE |
Engine type |
Single-Cylinder, Vertical, Four-Stroke, Direct Injection, Air Cooled Diesel |
Bore × Stroke(mm) |
78 x 62 |
Displacement (L) |
0.296 |
Rated Power KW |
3.68/3000 |
4.0/3600 |
Fuel comsumption Rate(g. kw/h) |
276.1 |
285.6 |
Compression Ratio |
20: 1 |
Lubrication System |
Pressure Splashed |
Starting System |
Electric Start with 30Ah MF battery |
Fuel Type |
0#(summer)-10#(winter) diesel |
Lube Oil Brand |
SAE10W30 (above CD Grade) |
Lube Capacity (L) |
1.1 |
Fuel Tank Capacity (L) |
12.5 |
Continuous Running Time (hr) |
12 |
Overall Dimension: LxWxH (mm) |
710 x 500 x 590 |
Dry Weight (Kg) |
70 |
Quantity in 20FT |
132 Pcs |
Optiomal Features: Remote, ATS(Auto Transfer Switch), Digital Panel |
We reserve the right to change specifications without notice |
Prod Model: |
KDE3500E |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Output Type: |
AC Three Phase |
Stroke: |
Four Stroke |
Installation Method: |
Portable |
Type: |
Self-Starting Diesel Generator |
Cooling Method: |
Air-Cooled |
National Machinery Group Co., Ltd. It is a professional supplier of Air-Cooled Diesel Engine (Model: KM170F, KM178F, KM186F, KM186FA, KM188F-A, KM188F-B), Water-Cooled Diesel Engine (Model: ZS195, ZS1100, ZS1105, ZS1110, ZS1115, ZS1125, ZS1130), Portable Generator (KDE2500E, KDE3500E, KDE6500E, KDE3700T, KDE6700T, KDE6700TA), Industrial Generator Set (Powered by Cummins, Perkins, Deutz, Yanmar, Kubota, Lovol, Weichai, Ricardo, Shangchai, Wudong, Quanchai etc), Power Tiller(Model: KDT-105, KDT-135), Welding Generator, Water pump set (Model: KDP20, KDP30, KDP40, KDP80T) etc, with 10 yers of experience in research, development and selling, we can supply you products with good quality and reasonable price.
