| Price: | US $ 30000/Set |
|---|---|
| Trade Terms: | FOB,CIF |
| Min Order: | 1/Set |
| Pay Type: | L/C,T/T |
| Model | Length | Width | Height |
| CCFJ150 | 2780 | 811 | 1660 |
| CCFJ170 | 2830 | 811 | 1660 |
| CCFJ190 | 2830 | 811 | 1660 |
| CCFJ210 | 2900 | 811 | 1660 |
| CCFJ240 | 2900 | 811 | 1660 |
| CCFJ270 | 3000 | 980 | 1660 |
| UNIT :mm | |||
|
Genset Model |
Engine Model |
Rated Power (kW) |
Fuel Consumption at Rated Power (L/hr) |
Genset Rated & Standby Output (k W / kVA) |
Genset Frequency (Hz) |
Genset Rated Voltage (V) & Current (A) |
Genset Net Weight (KG) |
| CCFJ150 | G128ZLCaf | 180 | 39.7 | 150/187 & 165/206 | 50 | 400 & 271 | 2040 |
| CCFJ170 | G128ZLCaf1 | 198.5 | 44.9 | 170/212 & 187/234 | 50 | 400 & 310 | 2200 |
| CCFJ190 | G128ZLCaf2 | 240 | 50.2 | 190/237 & 209/261 | 50 | 400 & 346 | 2210 |
| CCFJ210 | G128ZLCaf2 | 240 | 55.5 | 210/262& 231/289 | 50 | 400 & 375 | 2420 |
| CCFJ240 | G128ZLCaf3 | 276 | 63.4 | 240/300 & 264/330 | 50 | 400 & 426 | 2500 |
| CCFJ270 | SC15G500CF2 | 320 | 71.4 | 270/337 & 297/371 | 50 | 400 & 491 | 2680 |
| Prod Model: | 250GFC |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Fuel Oil: | MGO Only |
| Cooling Method: | Water Cooling |
| Stroke: | Four Stroke |
| Installation Method: | Fixed |
| Type: | Basic Diesel Generator |
| Output Type: | AC Three Phase |
| Landuse Type Of Unit: | Marine |
