| Price: | US $ 35000/Set |
|---|---|
| Trade Terms: | FOB,CIF |
| Min Order: | 1/Set |
| Pay Type: | L/C,T/T |
| Model | Length | Width | Height |
| CCFJ150 | 2540 | 840 | 1530 |
| CCFJ170 | 2680 | 840 | 1530 |
| CCFJ200 | 2680 | 840 | 1530 |
| CCFJ240 | 2630 | 850 | 1580 |
| CCFJ270 | 2680 | 840 | 1510 |
| CCFJ310 | 2770 | 840 | 1510 |
| UNIT :mm | |||
|
Genset Model |
Engine Model |
Rated Power (kW) |
Fuel Consumption at Rated Power (L/hr) |
Genset Rated & Standby Output (k W / kVA) |
Genset Frequency (Hz) |
Genset Rated Voltage (V) & Current (A) |
Genset Net Weight (KG) |
| CCFJ150 | WD10CD200E200 | 182 | 38.7 | 150/187 & 165/206 | 50 | 400 & 271 | 1800 |
| CCFJ170 | WP10CD238E200 | 216 | 43.9 | 170/212 & 187/234 | 50 | 400 & 310 | 1980 |
| CCFJ200 | WP10CD264E200 | 240 | 54.2 | 200/250 & 220/275 | 50 | 400 & 361 | 2180 |
| CCFJ240 | WP12CD317E200 | 288 | 61.9 | 240/300 & 264/330 | 50 | 400 & 426 | 2360 |
| CCFJ270 | WP13CD385E200 | 350 | 69.7 | 270/337& 297/371 | 50 | 400 & 491 | 2350 |
| CCFJ310 | WP13CD385E200 | 350 | 80.0 | 310/387 & 341/426 | 50 | 400 & 563 | 2450 |
| Prod Model: | 200GFC |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Fuel Oil: | MGO Only |
| Cooling Method: | Water Cooling |
| Stroke: | Four Stroke |
| Installation Method: | Fixed |
| Type: | Self-Starting Diesel Generator |
| Output Type: | AC Three Phase |
| Landuse Type Of Unit: | Marine |
