Model DP160 DP200 DP240 DP270 DP340 DP390
Type Single-cylinder, 4-stroke, OHV, air-cooled, gasoline engine
Bore x Strok mm 68x45 68x54 73x58 77x58 82x64 82x64
Displacement CC. 163 196 242 270 337 396
Compression Ratio 8.5: 1 8.5: 1 8.2: 1 8.2: 1 8.0: 1 8.0: 1
Max. Output HP/rpm 5.5/3600 6.5/3600 8.0/3600 9.0/3600 11.0/3600 13.0/3600
Max. Torque Nm/rpm 10.8/2500 13.2/2500 16.7/2500 19.1/2500 23.5/2500 25.5/2500
Fuel Tank Capacity L 3.6 3.6 6 6 6.5 6.5
Oil Capacity L 0.6 0.6 1.1 1.1 1.1 1.1
Fuel Consumption g/kw. H 313 313 308 308 303 303
Ignition System TCL (Transistorized contactless)
Dimensions(LxWxH) mm 430x380x390 520x455x475 540x480x505
NW/GW kg 16/17 17/18 25/27 25/27 31/33 31/33
20FT/40FT Load unit 516/1044 224/456 192/384
Optional Electric Start
Ningbo David Power Co., Ltd. is a leading manufacture specialized in engine, generator, engine pump and other power product.
It located at Ningbo City, near ShangHai in Zhejiang proveince. DAVID POWER reaches an annual production capability more than 200, 000sets of engine product.
David Power manage to deliver the superior quality products and service to every customer and company.
At DAVID we bring together technology and engineing to create solutions for the benefit of our customers.
