Product specification
50Hz cummins series generator set
Generator set Specifications: Diesel generator set, , generator set, diesel generator, generator, silent generator, soundproof / weatherproof canopy, genset, diesel genset
1) Cummins OEM Top Quality
2) Global warranty
3) ATS, AMF, Synchronization Optional
4) ISO approved supplier
5) Competitive Price with High Quality
4), Coupled to Stanford/Leroy Somer/Kaijie alternator
Scope of Supply:
1-Brand new engine and brushless AVR controlled alternator
2-Set mounted Smartgen Auto Controller
3-MCCB(Circuit Breaker), Emergency stop button, low oil pressure shutdown, high engine temperature shutdown.
4-Rubber Anti Vibration Mounts and skid basefram with 6-8hours integral fuel tank.
5-Genset equipped with battery charger and 24V high performance lead acid starting batteires and connecting with cables.
6-Genset equipped with industrial silencer and flexible exhaust hose.
7-Genset equipped with fan and closed circuit cooled radiator(40degree centigrade).
8-Genset with filtering systems including air filter, fuel filter & lub-oil filter.
9-Supply relative documents(testing report, diagram, operation/maintenance manual/spare parts manuals)for engine and alternator
Optional AST & ATS Control System:
AST (Automatic Start Type Control System), Optional Automatic Start Type System is provided with a 101A control module or a DACT704 module with LCD display. When there is an interruption in the commercial power supply (or there is a start signal in other generator sets), this generator set will, subject to time delay acknowledgement (0-30 S adjustable), be automatically started (1-8 times adjustable). In addition, it is provided with a basic protection function and digital or meter indication of voltage, current, frequency and rotation speed parameters.
ATS (Automatic Transfer System), The optional system is provided with a fully automatic transfer switch, a control electric apparatus and an indicator light on the control panel and is coordinated with an automatic type contral cabinet, thus serving the fuction of automatic changeover between the power supplied by the grid and the power generated by the genset.
Our factory
Genset model |
Output power |
RatedCurrent A |
Frequency/Speed
Hz/RPM |
Diesel Engine model |
Overall size(L×B×H)mm |
OverallweightKg |
KVA |
KW |
XZ24D |
30 |
24 |
43 |
50/1500 |
4B3.9-G2 |
1620×610×1380 |
610 |
XZ30D |
37.5 |
30 |
54 |
50/1500 |
4BT3.9-G2 |
1680×650×1400 |
680 |
XZ50D |
62.5 |
50 |
90 |
50/1500 |
4BTA3.9-G2 |
1760×710×1400 |
850 |
XZ75D |
93.75 |
75 |
135 |
50/1500 |
6BT5.9-G2 |
2150×830×1480 |
950 |
XZ100 |
125 |
100 |
180 |
50/1500 |
6BTA5.9-G2 |
2250×920×1600 |
1250 |
XZ120 |
150 |
120 |
216 |
50/1500 |
6BTAA5.9-G2 |
2250×920×1600 |
1350 |
XZ150 |
187.5 |
150 |
271 |
50/1500 |
6CTA8.3-G2 |
2400×1080×1600 |
1590 |
XZ160 |
200 |
160 |
288 |
50/1500 |
6CTAA8.3-G2 |
2600×1180×1600 |
1680 |
XZ180 |
225 |
180 |
324 |
50/1500 |
NT855-G |
3000×1180×1650 |
2400 |
XZ200B |
250 |
200 |
360 |
50/1500 |
MTA11-G2A |
3000×1180×1650 |
2400 |
XZ220 |
275 |
220 |
396 |
50/1500 |
NTA855-G1 |
3000×1180×1700 |
2600 |
XZ240 |
300 |
240 |
432 |
50/1500 |
NTA855-G1A |
3100×1180×1700 |
2680 |
XZ250 |
312.5 |
250 |
450 |
50/1500 |
MTAA11-G3 |
3100×1250×1650 |
2950 |
XZ260C |
325 |
260 |
468 |
50/1500 |
NTA855-G2 |
3100×1300×1700 |
3100 |
XZ300C |
375 |
300 |
540 |
50/1500 |
NTA855-G4 |
3200×1380×1750 |
3200 |
XZ320 |
400 |
320 |
576 |
50/1500 |
NTAA855-G7 |
3350×1450×1750 |
3250 |
XZ350 |
437.5 |
350 |
630 |
50/1500 |
NTAA855-G7A |
3350×1450×1750 |
3250 |
XZ400 |
500 |
400 |
720 |
50/1500 |
KTA19-G3 |
3400×1500×1780 |
3300 |
XZ420 |
525 |
420 |
756 |
50/1500 |
KTA19-G4 |
3450×1500×1800 |
3300 |
XZ450 |
562.5 |
450 |
900 |
50/1500 |
KTAA19-G5 |
3500×1600×1850 |
3500 |
XZ460 |
575 |
460 |
910 |
50/1500 |
KTAA19-G6 |
3600×1600×1850 |
3650 |
XZ470 |
587.5 |
470 |
920 |
50/1500 |
KTA19-G8 |
3600×1600×1850 |
3650 |
XZ500C |
625 |
500 |
990 |
50/1500 |
KTAA19-G7 |
3650×1650×1850 |
3750 |
XZ550 |
687.5 |
550 |
1000 |
50/1500 |
KT38-G |
3700×1650×1900 |
4000 |
XZ600 |
750 |
600 |
1188 |
50/1500 |
KTA38-G2 |
3800×1700×1980 |
4200 |
XZ650 |
812.5 |
650 |
1280 |
50/1500 |
KTA38-G2B |
4300×1850×2200 |
4800 |
XZ800 |
1000 |
800 |
1510 |
50/1500 |
KTA38-G5 |
4500×1950×2350 |
5600 |
XZ900A |
1125 |
900 |
1780 |
50/1500 |
KTA38-G9 |
4700×2050×2450 |
8500 |
XZ970 |
1212.5 |
970 |
1980 |
50/1500 |
KTAA38-G9A |
4800×2050×2450 |
8900 |
XZ1000 |
1250 |
1000 |
1890 |
50/1500 |
KTA50-G3 |
5400×2150×2550 |
9800 |
1320GFD |
1650 |
1320 |
2367 |
50/1500 |
TBD620V12G3 |
6040×2530×2650 |
11000 |
1496GFD |
1870 |
1496 |
2692.8 |
50/1500 |
TBD620V16G1 |
7650×2960×3060 |
13500 |
1584GFD |
1980 |
1584 |
2851.2 |
50/1500 |
TBD620V16G2 |
7650×2960×3060 |
13500 |
1760GFD |
2200 |
1760 |
3168 |
50/1500 |
TBD620V16G3 |
7650×2960×3060 |
14200 |
Qingdao Sanfengtai International Trade Co., Ltd. is a professional manufacturer and supplier of high quality diesel generator and accessories. The company has advanced production lines, sophisticated detection equipment, a complete quality management system, the number of highly qualified engineers and technicians. The business invloves all over the world.
Our factory is located in Dongying, Shandong province which has built a domestic advanced production line with functions of equipment, trial run and paint coating, and a modern laboratory of whole machine and accessories. The company always insists on the following quality policies and targets: Pushing the enterprise operating in the quality system which can be recognized by customes.
Keeping on the objectives of 'quality first, client supreme, all services for clients', Sanfengtai would like to create good future together with you.
