6.0KW Digital DC Generator GGDC6500S, with CE, GS, EPA certificate.
with this innovative digital DC generator of high efficiency, energy saving and environmental friendly, the running cost of telecommunications is greatly reduced. When there is no utility power, the DC output of digital DC generator ensures the load power supply and at the same time charges the battery, thereby meets the constant power demand for telecommunications devices.
Performance and features:
Energy-saving
Compared with traditional AC generator, DC generator are capable of reducing fuel consumption by 20%-25%
Convenient paralleling function
The DC generators can be paralleled together with two or more, without limitation on model or number. Appropriate power capacity and number of paralleling units can be selected to meet different loads.
Soft start
Current slowly rises after start to avoid the impact to communication loads and batteries. The max current can be steplessly and widely adjusted, which is applicable to the battery charging and load power supply for various base stations.
Large current, compact size and light weight
Compared with AC generator of same power with DC output through switch power supply, current will be larger by 52%.
Intelligent management on battery charging
Adaptable to quick charging. Prolong service life of accumulator. Charging process may be three steps: Constant flow, equalized charge and floating charge. The charging process complies with technical standards of YD/T 799-2000 "Technical Requirements and Test Methods of VRLA Battery for Telecommunication".
High automation
RS232/RS485 communication port can provide with open communication protocol, incorporate with the power environmental centralized monitoring network and realize remote control.
|
DC-Generator |
MODEL |
GGDC6500S |
|
Type |
Permanent magnet, brushless, bearing-less |
|
Voltage Regulate |
Automatism electronic regulate |
|
Rated Dc Output |
5.5KW |
|
Max Dc Output |
6.0KW |
|
Voltage output regulation |
0.5-1.0VDC |
|
Ripple quotiety |
150mV (when connecting on the battery) |
|
Rated Dc Voltage |
36/48/V |
|
Rated Current |
140/110A |
|
Run output Dc Voltage |
39/52.5V |
|
Gasoline Engine |
Model |
HD390FA |
|
Type |
OHV Forced Air-cooled, 4-Stroke |
|
Bore× Stroke |
1-88× 64mm |
|
Air cleaner |
Semi-dry double silent type |
|
Cooled way |
Air-cooled |
|
Displacement |
389ml |
|
Compression ratio |
8.2: 1 |
|
Max torque |
27.5/2500 N. m / rpm |
|
Ignition system |
Non-contact transistorized ignition(T. C. I) |
|
Spark plug gap |
0.7mm |
|
lubricating oil |
SF or Higher Grade |
|
lubricating oil capacity |
1.1L |
|
Lubrication system |
Pressure Splash |
|
Fuel consumption |
374(g/HP-hour) |
|
Power output |
13/3600(HP/ rpm) |
|
DC-Generator-Set |
Fuel |
Unleaded gasoline |
|
Starting system |
hand-operated/Electric start |
|
Noise level |
65dB |
|
Oil alarm |
No lube oil Auto stop safekeeping |
|
continuous operating |
7h |
|
Fuel capacity |
16L |
|
Front panel control system |
One-DC Output Socket, DC Output Pilot lamp. Over loading protect& Malfunction Pilot lamp |
|
Dimension L× W× H |
850*560*650mm |
|
Gross/ Net weight |
125/120 |
|
Unit(20FT) |
70 |
Established in July 2007, located in Weiyang district of Yangzhou, a city subordinate to Jiangsu province, Yangzhou Hengdong Mechanical & Electrical Co., Ltd is conveniently suited near freeway with ascendant investment environment. It arranges a settlement of 50 employees, among which there are 30 boasting academic certificate at or above the junior college level or obtaining junior superior title. Most of 8 technicians have served as Chief Engineer or Assistant Chief Engineer in the well-known generator manufacturing enterprises.
The company owns international advanced product research and development center, assembly line, machine performance test line, and generator component test table, which are all provided with computer-control system. Its leading product, HD power brand generators, can be widely applied in the home power solution, cars industry, army connection system, network system and telecom area.
Until now, with the certification of ISO9001, EPA, CARB and CE, the company has provided its products to a lot of different market which includes North & South America, Europe, Africa, Middle-east and Chinese local market.
Hengdong is not only an OEM factory, but also the strong backing of its client who researches and develops new suitable products every year for the ever-changing world wide market. We will be always keep going on improving the product value and creating long time partnership with all our world wide strategic partners.
