1. Low speed generator, use rare earth permanent magnet materials, strong overloading ability.
2. Use high-quality bearings, magnet and other components, the radiation heat is strong and demagnetization rate is low.
3. The body is made of high-quality steel pipes, have a good anti-corrosion treatment, prevent wind sand, prevent salt spray and other erosion.
4. With overcharge, over-discharge, exchange unloading and short-circuit protection, DC-constant voltage charging, run the simple, non-artificial unattended and special maintenance.
5. To install small occupancy area and on the geology require low, in the hills, the beach, river bank, desert terrain, etc. Can be installed under the conditions of use.
Item Parameter
Blades diameter(m) 6
Blade material and quantity 3 PCS Strenghthened form in one piece made by hand
Rated power(w) 5000
Max power(w) 6000
Annual power generation(kwh) 7500-22500
Rated rotor speed(r/min) 260
Start up wind speed(m/s) 2
Working wind speed(m/s) 4-25
Rated wind speed(m/s) 11
Security wind speed (m/s) 50
Working Voltage(v) AC160
Batteries Voltage(v)/Capacity(Ah) 220V200AH
Speedgoverning method Electromagnetic damping adjusting speed
Brake method Manual brade\security protection system
Generator Type Three phase and permanent magnet generator
Generator class of insulation F
Host weight
Guyed Tower Height/Weight(kg)
Free Stand Tower Height/Weight(kg)
Whole system package volume(m3)
Noise Level(dB) <65
Zibo CAT Wind Generator Co., Ltd. is a National high-tech enterprise specialized in research, development, marketing and sales of renewable energy products especially for wind power. The main products including Small and Medium wind generators, inverter & controller for photovoltaic system &wind system, solar and wind hybrid generators, solar and wind hybrid street light, wind-diesel hybrid system, wind-solar-diesel hybrid system. We provide project consulting, system design, technical support, and other services to the whole project process.
Company Located in Zibo City, China, Near 1 hour from Jinan airport, 3 hours from Qingdao port. Covering an area of 4000 square meters. CE certified, the company has a complete series of strict testing and quality guarantee methods for all of the products. The products has exported to numerous oversea markets: North America, UK, Ireland, India, Italy, France, etc; There is also a wide range of domestic application of these product on oil field, farmland, industry park, military camp, fishing farm and port warehouse as well.
